Zubehör
Unverzichtbare Lösungen, die die Installation, den Schutz und die Leistung von RF-Stecksystemen unterstützen
Übersicht
Das HF-Zubehör von Amphenol RF wurde entwickelt, um die Funktionalität, Haltbarkeit und Vielseitigkeit Ihres HF-Verbindungssystems zu verbessern. Diese breite Palette von Hochleistungskomponenten unterstützt alles, vom Steckerschutz und der Zugentlastung bis hin zur sicheren Schalttafelmontage und dem rationellen Kabelabschluss. Ganz gleich, ob Sie vor Ort installieren, einen Prüfstand konfigurieren oder kundenspezifische Baugruppen erstellen, unser Zubehör hilft Ingenieuren, saubere, zuverlässige und wartungsfreundliche HF-Systeme zu realisieren.
Unser Zubehörsortiment umfasst speziell angefertigte Backshells, Präzisionskomponenten, Hardware-Kits, Schutzkappen, Reduzieradapter, Zugentlastungsmanschetten und Kurzschlusskappen. Jedes Produkt ist auf mechanische Kompatibilität mit unseren HF-Steckverbindern ausgelegt und wird gemäß den Industriestandards für Leistung, Passform und Umweltbeständigkeit hergestellt.
Merkmale und Vorteile
- Umfassendes Zubehör: Backshells, Aderendhülsen, Kontakte, Muttern, Unterlegscheiben, Dichtungen und mehr
- Schutz von Steckern und Kabeln - Verwenden Sie Schutzkappen und Zugentlastungsmanschetten zum Schutz vor Abnutzung und Umwelteinflüssen
- Effiziente Installation und Wartung - Reduzieren Sie Ausfallzeiten durch einfach zu installierende Hardware, reduzierte Adapter und werkzeugfreundliche Montagelösungen
- Vielseitige Kompatibilität - Entwickelt für die Verwendung mit Steckerserien wie SMA, BNC, TNC, N-Type, HD-BNC, 1.0-2.3, Mini-UHF und anderen
- Verbesserte Zuverlässigkeit - Kurzschlusskappen und abgedichtete Optionen gewährleisten Signalintegrität und Umweltschutz, wo dies erforderlich ist
Wichtige technische Details
- Backshells und Schutzkappen sind für Hochfrequenzsteckertypen erhältlich
- Die Hardware umfasst Schraubenmuttern, Unterlegscheiben und Montagedichtungen für eine sichere Gehäuseintegration
- Komponenten (z. B. Kontakte, Aderendhülsen und Tape-and-Reel-Verpackungen) vereinfachen die Produktion in großem Maßstab
- Reduzieradapter ermöglichen eine nahtlose Verbindung zwischen verschiedenen Steckergrößen
- Ausgewählte Schutz- und Kurzschlusskappen bieten eine IP67-konforme Abdichtung
- Alle Zubehörteile sind präzisionsgefertigt oder spritzgegossen für mechanische Konsistenz
Anwendungen
- Prüf- und Messtechnik - Schützen Sie ungenutzte Anschlüsse, simulieren Sie Kurzschlussbedingungen und verwalten Sie die Kontaktpositionierung
- Feld- und Gehäuseinstallationen - Verwenden Sie Überwurfmuttern, Backshells und Zugentlastungsmanschetten, um Verbindungen in anspruchsvollen Umgebungen zu sichern
- Schaltschranksysteme mit hoher Dichte - Platzmanagement und Kompatibilität mit reduzierten Adaptern und flachen Zubehörteilen
- RF-Wartung und -Reparatur - Halten Sie Ihre Systeme sauber und schließen Sie sie mit Schutz- und Kurzschlusskappen richtig ab
Stöbern Sie in unserem vollständigen Katalog für HF-Zubehör, um die richtige Lösung für Ihr Systemdesign oder Ihre Feldanwendung zu finden. Für kundenspezifische Konfigurationen oder Hinweise zur Kompatibilität von Zubehör wenden Sie sich bitte an unser Anwendungstechnik-Team.
