RF-Adapter
Vielseitige, präzisionsgefertigte Koaxialadapter zum Verbinden, Konvertieren und Schützen von RF-Signalwegen über alle Standardschnittstellen
Übersicht
Die RF-Adapter von Amphenol RF bieten industrietaugliche In-Serien-, Zwischen-Serien- und T-Stück-Konfigurationen, die für eine zuverlässige Signalübertragung entwickelt wurden. Ganz gleich, ob Sie das Geschlecht wechseln, zwischen verschiedenen Steckertypen konvertieren oder Lösungen mit Schottmontage verwenden müssen, unsere Adapter sind so konzipiert, dass sie die Leistung bei HF-, Mikrowellen- und Datenanwendungen aufrechterhalten.
Jeder Adapter wird strengen Qualitätstests unterzogen, um eine hervorragende mechanische und elektrische Integrität zu gewährleisten. Ausgewählte robuste Versionen verfügen über eine IP-geschützte Versiegelung oder eine nicht-magnetische Konstruktion, die für Anwendungen von Laborinstrumenten bis hin zu rauen Außenumgebungen geeignet sind. Mehrere Serien unterstützen Broadcast-Grade-Konnektivität und militärisch zugelassene Anforderungen, was die Adapter von Amphenol RF zur ersten Wahl für präzises RF-Link-Design macht.
Eigenschaften und Vorteile
- Serieninterne und serienübergreifende Kompatibilität - Vielfältige Paarungen, einschließlich SMA, BNC, TNC, N-Type, AMC, SMP, SMB, RP-SMA, UHF, MHV, SMPM, HN-Type, T-Stücke und Schottvarianten.
- Connector-Saver-Funktionalität - Schützen Sie Ihre wertvollen Geräte, indem Sie den Verschleiß durch spezielle Gender-Change- und In-Series-Adapter minimieren.
- IP-zertifizierte und nicht-magnetische Optionen - Wasserdichte Varianten (z.B. IP67 Bulkhead N-Type) und nicht-magnetische Adapter sind ideal für sensible Umgebungen.
- Verfügbarkeit für Rundfunk und Militär - 50 Ω- und 75 Ω-Impedanzoptionen, einschließlich 12G-SDI-kompatibler BNC-Adapter, sowie QPL-zertifizierte Militärmodelle.
- Kompakte & Hochfrequenzdesigns - Miniaturformate wie AMC für Anwendungen bis zu 6 GHz sowie SMP/SMPM-Optionen für bis zu 40 GHz.
Wichtige technische Details
| Spezifikation | Einzelheiten |
|---|---|
| Impedanz | 50 Ω Standard; 75 Ω verfügbar für BNC und Mini-SMB (Broadcast/Video-Varianten) |
| Frequenzbereich | DC bis 6 GHz typisch; bis zu 12 GHz für BNC-Broadcast; SMP/SMPM-Varianten bis 40 GHz ausgelegt |
| Steckzyklen | Stecker-abhängig, z.B. SMA ~500; SMP/SMPM weniger aufgrund des Push-on-Designs |
| Temperaturbereich | -40 °C bis +85 °C allgemein; kann bei versiegelten oder speziellen Ausführungen variieren |
| Besondere Merkmale | IP67-zertifizierte Bulkhead-Designs, nicht-magnetische Materialien, QPL-zugelassene Modelle, 12G BNC-Optionen, T-Stück-Adapter |
Anwendungen
- Prüf- und Messtechnik - Bewahren Sie die Integrität der Instrumentierung mit Hilfe von Geschlechterwechslern und Steckverbinder-Saver-Adaptern.
- Rundfunk und Video - Bewahren Sie die 12G-SDI-Signaltreue mit 75 Ω BNC-Adaptern.
- Telekommunikation und drahtlose Infrastruktur - Verwenden Sie robuste, abgedichtete Adapter für Basisstationen im Freien.
- Militär und Luft- und Raumfahrt - Verwenden Sie QPL-zugelassene, nicht-magnetische Adapter in hochzuverlässigen Systemen.
- Industrie und raue Umgebungen - Wasserfeste Bulkhead- und T-Stück-Adapter sichern Signalwege unter extremen Bedingungen.
Durchsuchen Sie unser komplettes Portfolio an Standard-RF-Adaptern, um die für Ihre Signalkette geeignete Konfiguration zu finden. Für kundenspezifische Schnittstellenlösungen, Bulkhead-Konstruktionen oder abgedichtete/magnetische Versionen wenden Sie sich bitte an unsere technischen RF-Experten, um eine auf Ihre speziellen Anforderungen zugeschnittene Lösung zu entwickeln.
