Aktivieren Sie die Konnektivität in drahtlosen Kommunikationsmodulen mit MCX-Kabelkonfektionen
23.01.2026
Amphenol RF freut sich, die Erweiterung seines Kabelkonfektionsportfolios um MCX-Stecker in gerader und rechtwinkliger Ausführung bekannt zu geben, die mit robusten IP67-Durchführungsbuchsen vom Typ SMA, TNC, RP-TNC und N-Type ausgestattet sind. Diese Konfektionen basieren auf einem flexiblen RG-316-Kabel, das eine hervorragende elektrische Leistung bis zu 6 GHz sowie eine hohe Hitzebeständigkeit, Langlebigkeit und geringe Signalverluste in Hochfrequenz-HF-Anwendungen bietet. Diese serienübergreifenden Konfektionen ermöglichen den Anschluss eines Kabels von außerhalb einer Schalttafel, wo sich eine Gewindeverbindung befindet, und sind speziell für drahtlose Kommunikationsmodule mit MCX-Steckverbindern auf der Platine konzipiert.
Die Kombination aus MCX, das regelmäßig auf der Platine verwendet wird, und robusteren Steckverbindern bietet eine Vielzahl von Einsatzmöglichkeiten, darunter tragbare Geräte, GPS, Wi-Fi und innerhalb von Fahrzeugkonstruktionen wie landwirtschaftlichen Baumaschinen, Erdbewegungsmaschinen, Bergbaumaschinen und anderen schweren Industrieanlagen. Die Steckverbinder außerhalb der Schalttafel sind abgedichtet, um das vorübergehende Eindringen von Wasser und anderen Flüssigkeiten zu verhindern. Dadurch wird das Risiko ausgeschlossen, dass das System durch äußere Einflüsse beeinträchtigt wird.
Diese Baugruppen ergänzen eine wachsende Auswahl an vorkonfigurierten Kabeln, die für die Unterstützung von Funkmodulen entwickelt wurden, die extern mit Antennen verbunden sind und eine robustere Lösung erfordern, um sicherzustellen, dass das System nicht durch Witterungseinflüsse oder Manipulationen beeinträchtigt wird. Diese Baugruppen können über unsere Vertriebspartner in Standardlängen von drei bis 48 Zoll erworben werden.
Ansicht: MCX-Kabelbaugruppen auf RG-316-Kabel-Datenblatt
