Verbessern Sie die Sicherheit Ihrer Geräte mit einer manipulationssicheren BNC-Durchführungsbuchse für 1,13-mm-Kabel.
16.10.2025
Amphenol RF freut sich, die Einführung einer manipulationssicheren BNC-Schottbuchse für flexible 1,13-mm-Mikrokoaxialkabel bekannt zu geben. Dieser Panel-Mount-Steckverbinder wurde für robuste Zuverlässigkeit bis zu 9 GHz entwickelt, um die Wi-Fi 7-Technologie zu unterstützen. Dieser BNC-Steckverbinder eignet sich hervorragend für Test- und Messanwendungen, Telekommunikation und industrielle Anwendungen.
Diese neue BNC-Durchführungsbuchse verfügt über einen vernickelten Messingkörper und vergoldete Berylliumkupferkontakte. Diese Materialien sind für raue Umgebungen ausgelegt und gewährleisten eine konstante Signalintegrität und Hochfrequenzfähigkeit. Durch sein geringes Gewicht eignet sich dieser Steckverbinder ideal für Designs mit begrenztem Platzangebot.
BNC-Steckverbinder für Mikrokoaxialkabel sind Teil eines wachsenden Angebots an HF-Verbindungslösungen, die als Standardlösungen erhältlich sind.
Alle anzeigen: BNC-Durchführungsbuchsen
