N-Type Straight Plug IP67 to N-Type Straight Plug IP67 LMR-400 50 Ohm 36 inches ARC
095-909-173-036
Teil Status:
Active
Produktspezifikationen
Siehe Simular
Produktspezifikationen
| Attribute | Einzelheiten |
Siehe Simular
Wählen Sie die nachstehenden Attribute, um ähnliche Produkte anzuzeigen
|
|---|---|---|
| Applications |
Ruggedized, Waterproof IP Rated
|
|
| Armor Option |
Without Armor
|
|
| Cable Assembly Length |
36.00 in (914 mm)
|
|
| Cable Assembly Type |
in-Series
|
|
| Cable Config |
N-Type Plug to N-Type Plug
|
|
| Cable Config 2 |
N-Type Pl Str IP67 to N-Type Pl Str IP67
|
|
| Cable Type Cable Assemblies |
Times LMR-400
|
|
| Country of Origin |
MX
|
|
| ECCN |
EAR99
|
|
| Frequency (Max GHz) |
6
|
|
| HTS Code |
8544.20.0000
|
|
| Impedance (Ohms) |
50
|
|
| IP Rating |
IP67
|
|
| Low PIM |
No
|
|
| Mil Qualified |
Not Mil Qualified
|
|
| Non Magnetic |
Contains Magnetic Materials
|
|
| Panel Mounting Feature |
Not Applicable
|
|
| PFAS |
Contains PFAS
|
|
| Temp (Max Degrees Celsius) |
85
|
|
| Temp (Min Degrees Celsius) |
-40
|
|
| Unit Weight (Grams) |
190.960
|
|
Alle zugehörigen Dokumente
Alle zugehörigen Dokumente
| Titel des Dokuments | Typ | Datum der Veröffentlichung |
|---|---|---|
| 095-909-173-XXX PDF Customer Drawing (Größe: 292 KB) | pdf |
01.04.2025 |
