后壳
为坚固系统中的射频连接器提供强大的端接保护、电磁干扰屏蔽和应变消除功能。
概述
Amphenol 射频后壳设计用于保护电缆到连接器的终端，为各种射频连接器接口提供机械支持、屏蔽和可选的环境密封。我们的后壳提供串内和串间设计，以匹配行业标准连接器类型。
无论是部署在恶劣的现场环境、密集的射频机架还是紧凑的嵌入式模块中，后壳都能通过管理电缆烧毁、屏蔽过渡和配接接口的机械应力，帮助保持信号完整性和长期可靠性。
特点和优势
- 应力消除和机械保护- 后壳可固定电缆束、控制弯曲半径并防止连接器接合处疲劳
- EMI / RFI 屏蔽连续性- 导电后壳设计有助于保持屏蔽连续性并减少杂散辐射
- 紧凑坚固的设计- 后壳可在狭小空间或高振动系统中使用
- 可定制配置- 对于非标准几何形状或极端环境，我们的工程团队可量身定制解决方案
主要技术细节
- 阻抗
通常为 50 Ω（某些变体专为 75 Ω 应用而设计） - 频率范围
取决于连接器；典型的后壳支持与配对连接器相同的射频频率范围（注：实际可用带宽受电缆限制） - 配接周期
大约 500 次或更多（因连接器系列和连接器到电缆组件配置而异） - 温度范围
常见范围：-65 °C 至 +165 °C（实际范围取决于连接器材料、电镀和电缆结构）
应用
当射频连接器遇到实际的机械和环境压力时，后壳是不可或缺的。典型用例包括
- 电信基站和回程基础设施
- 广播和视频制作设备
- 测试和测量系统
- 军事、航空航天和国防平台
- 坚固耐用的仪器和传感器系统
- 任何需要可靠屏蔽过渡和应变控制的电缆组件
要了解现有的标准后壳零件，请浏览下面的产品列表。如果您的应用需要定制布局、密封选项或机械调整，请联系我们的工程团队，根据您的要求定制后壳解决方案。
