HD-EFI 连接器
微型 50 Ω 板对板射频连接器，具有高浮动和盲配功能
概述
Amphenol RF 的 HD-EFI 连接器经过精密设计，适用于要求对准公差和高频性能的紧凑型多层 PCB 互连。它们设计有较大的轴向和径向 "浮动"，支持盲插，并能适应板与板之间的间距变化--非常适合模块化无线系统和密集的电子设备。
HD-EFI 具有高达 6 GHz 的可靠射频性能和紧凑的推入式接触几何形状，可确保在多次插配过程中保持稳定的信号完整性。该系列提供常见的 PCB 插座和电缆插头格式，以及用于灵活电路板堆叠的子弹头适配器，是宽带路由器、军事/航空设备和电信基础设施的理想之选。
特性和优点
- 高浮动公差：±0.7 毫米轴向偏差和 ±0.3 毫米径向偏差，支持易出错的装配条件。
- 盲插能力：采用防碰撞、封闭式设计，可在插配过程中保护触头。
- 结构紧凑、模块化：微型接口可在小型印刷电路板上支持多条射频线路。
- 高达 6 GHz 的 50 Ω 性能确保了宽带通信质量。
- 多种格式：PCB 插座、电缆插头和子弹头适配器可灵活堆叠。
主要技术细节
- 阻抗：标称 50 Ω（宽带系统）
- 频率范围：DC-6GHzDC-6 GHz，在盲配范围内性能一致
- 额定电压连续 335 VRMS，介质耐压高达 1 000 VRMS
- 耦合机制：推入式盲插、抗冲击触点
- 机械浮动：±0.7 毫米轴向/±0.3 毫米径向，可处理 PCB 差异
应用
- 模块化电信和宽带路由器
- 军用和航空航天通信模块
- 仪器仪表和医疗系统中的多网络 PCB 堆栈
- 车辆和国防无线板对板组件
- 具有严格对齐公差的紧凑型射频系统
浏览我们的 HD-EFI 系列产品，包括表面贴装 PCB 插座、直角电缆插头和各种子弹头适配器，以实现精确的堆叠配置。如需定制电路板间距公差、电缆到电路板过渡或定制集成解决方案，请联系我们的工程团队，设计适合用途的接口。
Specifications
HD-EFI Connectors
Electrical
| Impedance | 50 Ohm |
| Frequency Range | DC - 6 GHz |
| Voltage Rating | 335 Volts RMS Continuous |
| Dielectric Withstanding Voltage | 1000 Volts RMS Max |
| VSWR (Return Loss) |
|
|
Axial Misalignment ± 0.7 mm
|
|
|
DC - 2 GHz
|
1.14 (-24 dB) Max |
|
2 - 4 GHz
|
1.22 (-20 dB) Max |
|
4 - 6 GHz
|
1.38 (-16 dB) Max |
|
Axial Misalignment ± 0.3 mm
|
|
|
DC - 2 GHz
|
1.08 (-28 dB) Max |
|
2 - 4 GHz
|
1.12 (-25 dB) Max |
|
4 - 6 GHz
|
1.2 (-21 dB) Max |
| Insulation Resistance | 5000 MΩ Min |
| Center Contact Resistance | 5 mΩ Max |
| Outer Contact Resistance | 5 mΩ Max |
| Insertion Loss |
|
|
DC - 3 GHz
|
-0.14 dB Max |
|
3 - 6 GHz
|
-0.27 dB Max |
| 3rd Order Intermodulation | 930 & 955 MHz (2X43 dBm), -163dBc Max (Low PIM Designs) |
| Power Handling | 40 W Max @ 2.6 GHz @ 95ºC |
|
|
120 W Max @ 2.5 GHz @ 95ºC |
Environmental
| Temperature Range | −45°C to +125°C |
| Thermal Shock | MIL-STD-202, Method 107, Condition B |
| Corrosion | MIL-STD-202, Method 101, Condition B - 5% Salt Spray |
| Vibration | MIL-STD-202, Method 204, Condition B |
| Mechanical Shock | MIL-STD-202, Method 213, Condition A - No Discontinuity Permitted |
| Humidity/Temperature Cycling | MIL-STD-202, Method 106, Condition A |
| Temperature Life | 250 Hours at 125° C, No Damage to Parts |
Mechanical
| Mating Cycles | 50 Min (Limited Detent), 200 Min (Smooth Bore) |
| Coupling Mechanism | Push-On |
| Interface Specification | Amphenol RF Proprietary |
| Engagement Force | 12 N Max (Smooth Bore), 25 N Max (Limited Detent) |
| Disengagement Force | 2 - 6 N (Smooth Bore), 9 N Min (Limited Detent) |
| Mechanical Misalignment |
|
|
Axial
|
±0.7 mm |
|
Radial
|
±0.7 mm |
|
Max Float Angle
|
5⁰ Surface Mount Parts, 3.5⁰ Through-hole Mount Parts |
|
Min Board to Board Distance
|
11.46 mm |
Note: These characteristics are typical and may not apply to all connectors.
Connector configurations may affect performance.
