AUTOMATE A 型连接器
专为现代汽车系统设计的微型高速 Mini-FAKRA 连接器
概述
Amphenol RF 的 AUTOMATE A 型连接器系列重新定义了汽车射频互连，与传统的 FAKRA 连接器相比，其封装尺寸缩小了 80%。它们采用紧凑型推入式设计和彩色编码外壳，支持高达 20 Gbps 的数据传输速率，适用于新兴汽车应用。这些连接器的设计具有汽车级的坚固性，可简化装配并防止大批量生产中的错配。
专为下一代车载系统（如 ADAS、环视摄像头和 3D 仪表板）而优化的 AUTOMATE Type A 连接器既节省空间，又提高性能。它们提供多端口外壳选项、低啮合力（≤ 50 N）和端子位置保证，设计用于轻松安装、可靠固定和兼容现有 Mini-FAKRA 器件。
特点和优点
- 超紧凑设计：与标准 FAKRA 相比，最多可节省 80% 的安装空间
- 高速性能：高达 20 Gbps（电缆版本额定频率为 15 GHz
- 彩色编码和彩色按键：七种机械按键代码和通用 "Z "代码，防止错配
- 低啮合力：≤ 50 N 输入，≥ 5 N 输出，提供可靠的免工具服务
- 强大的保持功能：端子位置保证 (TPA)、封闭式输入电缆接口和可选的连接器位置保证 (CPA)
主要技术细节
- 阻抗：标称 50 Ω，符合汽车射频标准
- 频率范围PCB 版频率可达 9 GHz；电缆版频率可达 15 GHz（取决于电缆）
- 连接器系列：推入式耦合，零适配器干扰
- 支持的电缆TFC-302LL 及同类产品、RG-174、RG-316 汽车线束中常见的电缆
- 耐久性：≥ 25 次配接循环；中心和外部接触电阻 < 5 mΩ；工作电压 750 VRMS
- 环境额定值：-40 °C 至 +105 °C 工作温度
应用
- 360° 环视摄像系统
- 自动驾驶和高级驾驶辅助系统 (ADAS)
- GPS 导航和 V2X 车辆通信
- 高带宽信息娱乐和 3D 仪表盘
- 远程启动、车辆控制系统和线对板模块
浏览我们的 AUTOMATE A 型连接器系列，了解直插式和直角式单端口、双端口和四端口配置。如需了解定制电缆组件或独特的汽车规格，请联系我们，探讨量身定制的解决方案。
Specifications
AUTOMATE® Type A Connectors
Electrical
| Impedance | 50 Ohm Nominal |
| Frequency Range | DC - 9 GHz |
| Dielectric Withstanding Voltage | 750 VRMS Min. |
| Return Loss | |
|
DC - 3 GHz
|
1.12 (-25dB) Max. |
|
3 - 6 GHz
|
1.22 (-20 dB) Max. |
| Current Rating | ≤2A DC |
| Center Contact Resistance | <5mΩ |
| Outer Contact Resistance | <5mΩ |
Environmental
| Temperature Range | -40˚C to +105˚C
|
| RoHS | Compliant with Exemption 6C
|
Mechanical
| Mating Cycles
|
25 Min. |
| Coupling Mechanism
|
Push-On
|
| Engagement Force | ≤50N
|
| Disengagement Force
|
≥5N
|
Note: These characteristics are typical and may not apply to all connectors.
Connector configurations may affect performance.
