变径适配器
不同射频连接器尺寸和类型之间的无缝接口转换。
概述
变径适配器为不同连接器接口或尺寸之间的转换提供了一种方便、高性能的方式--无论是将较小的连接器配接到较大的插孔中，还是反之亦然。在 Amphenol RF，我们的缩径适配器有系列内和系列间两种配置，涵盖多种射频连接器类型，并针对最小插入损耗和阻抗连续性进行了优化。
这些适配器可帮助您处理连接器不匹配问题，而无需重新设计电缆线路，从而使系统升级或互连改造更具灵活性。无论您是需要在实验室仪器、电信系统还是广播设备的同轴连接器之间进行适配，我们的还原适配器都能在转换过程中保持信号完整性。
特点和优势
- 低插入损耗和优化的性能--旨在将过渡期间的信号衰减降至最低
- 与 Amphenol 射频连接器高度兼容- 设计用于与我们的连接器系列正确配接，实现无缝集成
- 紧凑、可现场使用的外形- 占用空间小，可用于密集或受限的布局，而不会产生明显的间距损失
- 耐用的机械设计- 坚固的机械耦合和材料适合反复使用和环境压力
主要技术细节
- 频率范围
可用频率范围取决于正在缩小的连接器接口；适配器的设计可避免干扰标称工作频带（实际限制取决于连接器、电缆和适配器的几何形状） - 配接周期
许多变径适配器在适当条件下可进行数百次配接循环（因接口类型和机械设计而异） - 温度范围
典型的工作温度范围约为 -65 °C 至 +165 °C（实际限制可能取决于电镀、绝缘体材料和特定的连接器接口） - 特点
紧凑的几何形状、最小的外形过渡、高耐用性、EMI 屏蔽连续性（如适用）、耐腐蚀电镀
应用
减小适配器在各种射频系统中起着至关重要的作用，在这些系统中，接口的兼容性和灵活性至关重要：
- 需要同轴测试端口之间适配器的测试和测量系统
- 现有电信和广播系统的改造或升级
- 存在不匹配连接器类型的设备互连
- 需要频繁重新配置的实验室或工作台系统
- 连接器标准化面临挑战的广播、无线、仪器仪表和通信系统
- 在现场安装时，更换电缆不现实，但需要对连接器进行调整
请在变径适配器产品部分查看我们现有的变径适配器产品组合。如果您的系统需要定制的减径几何形状、特殊阻抗或机械适配，请联系我们的工程团队，为您量身定制适配器解决方案。
