射频适配器
用途广泛、设计精密的同轴适配器可连接、转换和保护所有标准接口的射频信号路径
概述
Amphenol RF 的射频适配器提供行业标准的串内、串间和三通配置，专为可靠的信号传输而设计。无论您需要改变性别、转换连接器类型还是使用隔板安装解决方案，我们的适配器都能在射频、微波和数据应用中保持性能。
每个适配器都经过严格的质量测试，以确保出色的机械和电气完整性。精选的加固型适配器具有 IP 级密封或无磁性结构，适用于从实验室仪器到恶劣户外环境的各种应用。多个系列支持广播级连接和军用认证要求，使 Amphenol RF 适配器成为精密射频链路设计的首选。
特点和优势
- 系列内和系列间兼容性- 广泛的配对，包括 SMA、BNC、TNC、N 型、AMC、SMP、SMB、RP-SMA、UHF、MHV、SMPM、HN 型、三通和隔板变体。
- 连接器保护功能- 通过专用的性别转换和系列内适配器，最大限度地减少磨损，从而保护贵重设备。
- IP 防护等级和非磁性选项- 防水变体（如 IP67 N-Type 隔板）和非磁性适配器，是敏感环境的理想选择。
- 广播和军用可用性- 50 Ω 和 75 Ω 阻抗选项，包括兼容 12G-SDI 的 BNC 适配器，以及 QPL 认证的军用型号。
- 紧凑型高频设计- AMC 等微型格式适用于高达 6 GHz 的应用，SMP/SMPM 选件适用于高达 40 GHz 的应用。
主要技术细节
| 规格 | 详细信息 |
|---|---|
| 阻抗 | 标准阻抗为 50 Ω；BNC 和 Mini-SMB 可提供 75 Ω（广播/视频变体） |
| 频率范围 | DC 至 6 GHz（典型值）；BNC 广播频率高达 12 GHz；SMP/SMPM 变体额定频率高达 40 GHz |
| 配接周期 | 取决于连接器，例如 SMA ~500；由于采用推入式设计，SMP/SMPM 更少 |
| 温度范围 | 常见 -40 °C 至 +85 °C；可能因密封或特殊构造而异 |
| 特殊功能 | IP67 防护等级的隔板设计、非磁性材料、QPL 认证型号、12G BNC 选件、三通适配器 |
应用
- 测试与测量- 使用性别转换器和连接器保护适配器保持仪器完整性。
- 广播与视频- 使用 75 Ω BNC 适配器保持 12G-SDI 信号的保真度。
- 电信与无线基础设施- 将坚固耐用的密封适配器用于室外基站。
- 军事和航空航天- 在高可靠性系统中使用 QPL 批准的非磁性适配器。
- 工业和恶劣环境- 防水隔板和三通适配器可在极端条件下确保信号通路安全。
浏览我们完整的标准射频适配器产品组合，找到适合您信号链的配置。如需定制接口解决方案、隔板或密封/磁性版本，请联系我们的射频技术专家，为您量身定制解决方案。
