AMC 适配器
超小型卡入式射频适配器在 AMC 和标准射频接口之间提供多功能转换，具有紧凑的板对电缆功能。
概述
Amphenol RF 的 AMC 适配器是空间受限的射频板级电路与行业标准连接器之间的关键纽带。这些适配器专为系列内和系列间的无缝转换而设计，包括 AMC 至 SMA、AMC 至 TNC、AMC 至 N-Type、AMC 至 MMCX 以及探头至 SMA 等配置。这些适配器采用卡入式耦合，尺寸小巧，非常适合便携式无线设备和嵌入式射频解决方案。
每个适配器都采用精密 PTFE 介电材料、镀银主体和严格的公差，以保持高达 6 GHz 的信号完整性。穿板式和法兰式版本支持面板安装，经久耐用，是测试、物联网和电信应用的理想之选。AMC 适配器利用安费诺的 AMC 连接器生态系统，该系统兼容 Hirose U.FL® 和 I-PEX MHF I / MHF I LK® 系列，实现了与微同轴系统的广泛集成。
特点和优势
- 卡入式使用方便- 无需工具即可快速插接，啮合牢固，性能可重复。
- 紧凑的尺寸 - 超紧凑的尺寸使印刷电路板占用空间最小。
- 广泛的转换支持 - 提供 AMC 至 SMA、AMC 至 TNC、AMC 至 MMCX、AMC 至 N 型和探针适配器。
- 面板就绪隔板- 提供直隔板和 2/4 孔法兰安装版本，可实现稳健的面板集成。
- 高达 6 GHz 的 50 Ω 性能 - 确保为新一代射频设计提供低驻波比和插入损耗。
应用
- 物联网和便携式设备- 使用 AMC 接口的 GPS、蓝牙和嵌入式无线模块的理想之选。
- 无线基础设施- AMC 至 N 型适配器，用于在紧凑型系统中集成测试端口。
- 测试与测量- AMC 至 SMA/TNC 适配器通过隔板安装保护贵重仪器。
- 射频干扰器和安全设备- 卡入式简便性支持现场可更换模块。
- 嵌入式和可穿戴电子设备- 板到系统的紧凑型转换，支持小型化设计目标。
