AMMC 适配器
超小型 AMMC 适配器为需要密集连接的板级系统提供紧凑的卡入式射频转换。
概述
Amphenol RF 的 AMMC 适配器是超微型板装射频接口与标准电缆连接器之间的桥梁，适用于需要小尺寸和可靠性能的应用。该产品系列具有串内（AMMC-AMMC）和串间转换（如 AMMC-SMA）功能，可确保物联网设备、测试模块和嵌入式系统的无缝连接。
这些适配器采用与连接器相同的 AMMC（安费诺超微型同轴）2 mm × 2 mm 基底面和 1.4 mm 配接高度，可在高密度设计中实现盲插或面板友好配置。AMMC 适配器采用精密设计的 PTFE 绝缘体、电镀主体和卡入式耦合，支持高达 6 GHz 的频率，在恶劣环境中具有稳定的电气性能。
特点和优势
- 超小型尺寸- 基底面仅为 2 mm × 2 mm，配接高度为 1.4 mm，最大限度地减少了 PCB 空间。
- 卡入式可靠性- 免工具啮合，配接一致，适用于紧凑型自动化装配。
- 灵活配置- 支持 AMMC-AMMC 系列内和 AMMC-SMA 系列间转换。
- 高频性能- 专为高达 6 GHz 的宽带射频使用而设计。
- 高密度射频布局兼容性- 是紧凑系统中板对板或板对电缆解决方案的理想选择。
应用
- 物联网和可穿戴设备- 紧凑型 AMMC-SMA 适配器可在微型电子设备中实现外部天线连接。
- 嵌入式无线模块- 内部板对板 AMMC 转换器支持 GPS、BLE 和其他射频路径。
- 测试和测量设备- 卡入式隔板适配器是测试夹具和微型仪器的连接器保护器。
- 射频传感器和仪器模块- AMMC 接口可实现模块化电路板堆叠和高密度信号路由。
- 消费电子和微型天线系统-微型多板组件中坚固的射频连接。
所有 AMMC 适配器类别
