F 型适配器
可靠的 75 Ω F 型适配器可实现电视、电缆和宽带射频系统的无缝同轴连接。
概述
.jpg)
Amphenol RF 的 F 型适配器提供完整的系列内和系列间配置，从 F 型到 BNC、N 型、SMA、SMB 等，专为高性能射频系统而设计。这些适配器有直型、直角型、隔板型和法兰安装型，可确保在各种应用中灵活安装。
这些适配器采用精密加工的黄铜本体和镀金触点，支持高达数 GHz 的 75 Ω 电缆系统（带宽取决于电缆类型和连接器配对）。它们是广播、住宅、商业和测试环境的理想选择--提供可靠的转换并保护仪器端口。
功能和优点
- 全面的适配器范围- 包括 F 型在线（插头到插头/插孔到插孔）和系列间适配器（F 型到 BNC、N 型、SMA、SMB 等）。
- 节省空间的直角和闷头式- 狭窄安装和外壳安装使用的理想选择。
- 广泛的射频能力- 在 75 Ω 系统中有效，最高可达数个 GHz，具体取决于电缆。
- 连接器保护实用程序- 系列内适配器可在频繁配接过程中保护设备端口。
- 耐用的结构- 黄铜结构，螺纹或隔板连接，确保持久的性能。
应用
- 有线和卫星电视安装- 灵活的同轴基础设施在线和面板馈电选项。
- 住宅和商业宽带- 用于 DVR、调制解调器和墙板射频路径路由的适配器。
- 测试与仪器- 桶型适配器是实验室或现场设置中的连接器保护器。
- 无线与安全系统- 用于 CCTV、Wi-Fi 和物联网设备的 F 型直插式或面板适配器。
- 广播和分配网络- 实现媒体环境中射频接口之间的轻松连接。
