N 型适配器
坚固耐用的高频适配器，专为在恶劣环境中实现精确的射频性能而设计。
概述
.jpg)
Amphenol RF 的 N 型适配器设计用于在要求苛刻的应用中支持坚固耐用的高频 RF 连接。这些螺纹适配器可提供安全稳定的连接，是振动和环境因素影响较大的系统的理想选择。N 型适配器有多种配置可供选择，包括系列间和系列内选项，其耐用性和电气性能深受多个行业的信赖。
N 型接口以其稳定的 11 GHz 性能和耐候性设计而著称，是室内和室外射频应用的理想选择。Amphenol RF 的产品系列包括直型和直角型、隔板选项，以及配接时符合 IP67 密封要求的解决方案，即使在恶劣的现场环境中也能确保可靠的性能。
特点和优点
- 安全的螺纹耦合机制确保了在易振动环境中的可靠连接
- 频率性能高达 11 GHz，支持宽带和无线应用
- 提供系列内和系列间配置，实现灵活的系统集成
- 提供 IP67 密封变体，适用于室外和恶劣环境
应用
- 无线基础设施- 适用于基站设备中的户外和塔式安装组件
- 军事和航空航天 - 用于坚固耐用的通信和雷达系统
- 仪器仪表- 支持需要稳定、可重复连接的测试和测量设置
- 工业物联网- 传感器网络在潮湿或振动环境中的可靠性
所有 N 型适配器类别
