SMC 适配器
多功能超小型适配器在紧凑的空间内提供安全的螺纹耦合和可靠的射频性能。
概述
Amphenol RF 的 SMC 适配器为空间有限且性能可靠的射频应用提供坚固灵活的连接。这些超小型适配器采用螺纹连接机制，具有抗振性，适用于紧凑型便携式设备的半永久连接。SMC 适配器提供串内和串间配置，支持不同射频接口之间的无缝集成。
SMC 适配器专为直流至中频应用而设计，适用于测试与测量、电信和 GPS 系统等多个行业。它们体积小巧，电气性能稳定，非常适合需要耐用、节省空间的互连解决方案的设计。
特性和优点
- 螺纹耦合确保安全和抗振连接
- 提供串内和串间配置，提高设计灵活性
- 结构紧凑，支持高密度应用
- 从直流到 4 GHz 的可靠性能
主要技术细节
- 50 Ω 阻抗，适用于标准射频应用
- 黄铜和铍铜材料，镀金处理，耐腐蚀，经久耐用
- 支持直流至 4 GHz（取决于配置
- 通过系列间适配器与多个射频系列兼容
应用
- GPS 系统- 为紧凑型导航电子设备提供可靠的信号互连。
- 电信设备- 用于小型基础设施硬件中的信号路由。
- 测试和测量设备- 在射频测试装置中实现紧凑、稳定的互连。
- 消费电子产品- 支持紧密集成电子组件中的射频功能。
