SSMB 适配器
专为空间受限的高频应用而设计的紧凑型超小型互连器件。
概述
SSMB 适配器提供可靠、紧凑的射频解决方案，适合密集的系统布局和高性能要求。这些适配器专为满足现代射频系统的要求而设计，在保持出色电气性能的同时，还能实现安全的卡入式配接功能。
这些超小型适配器通常用于电路板空间有限而射频性能至关重要的电信、军事和测试设备环境中。Amphenol RF 提供各种 SSMB 适配器配置，以支持系统的灵活性和易集成性。
特点和优点
- 超小型尺寸支持紧凑型 PCB 和外壳设计
- 卡入式耦合确保快速安全的连接
- 提供一系列系列内和系列间配置
- 设计用于实现高达 4 GHz 的稳定射频性能
主要技术细节
- 接口：SSMB（提供系列内和系列间选项）
- 耦合机制卡入式
- 本体样式： 直形和直角直线和直角
- 提供插孔和插头接口，可灵活集成
- 请浏览我们提供的标准产品，或联系我们讨论您的定制射频适配器要求。
应用
- 航空航天和国防系统- 支持紧凑型通信模块和导航系统。
- 电信设备- 实现交换和信号路由硬件的密集电路板布局。
- 测试和测量- 为精密仪器提供安全的信号接口。
- 医疗成像设备- 适用于诊断设备中的紧凑型射频模块。
