三同轴适配器
多功能屏蔽解决方案专为电磁干扰敏感环境中的高完整性信号传输而设计。
概述
Amphenol RF 的三同轴适配器专为需要卓越信号保护和稳健连接的应用而设计。这些适配器采用三层屏蔽设计，与标准同轴接口相比，具有出色的 EMI/RFI 屏蔽性能。因此，这些适配器非常适合用于必须将电气干扰降至最低的关键任务通信和仪器仪表系统。
这些互连器件通常用于专门的广播、医疗和军事系统，可在三轴连接器之间灵活地进行布线和配接配置。Amphenol 射频三轴适配器由耐用材料制成，并按照严格的公差进行精密加工，在严苛的环境中长期使用仍能保持机械完整性和信号可靠性。
特点和优点
- 三层屏蔽设计加强了 EMI/RFI 保护
- 适用于精密信号和低噪声环境
- 提供插孔对插孔、插头对插头和插孔对插头配置
- 结构坚固，具有长期的机械可靠性
- 与标准三轴连接器兼容
应用
- 广播和演播室设备
- 军用级通信系统
- 敏感的医学成像和诊断工具
- 实验室仪器和测试环境
- 需要 EMI 屏蔽的工业控制系统
