双绞线连接器
专为在苛刻环境中传输差分信号而设计的强大射频解决方案
概述
Amphenol RF 的 Twinax 连接器专为平衡传输线应用而设计，这些应用要求出色的抗噪能力和最小的信号衰减。这些连接器采用双导体接口，支持高速和高可靠性系统常用的差分信号。Amphenol RF 的 Twinax 解决方案包括各种连接器样式和接口配置，是传统和现代应用的理想之选，可降低电磁干扰 (EMI)。
这些连接器采用标准和定制格式，具有坚固的机械性能、一致的电气特性和易于安装的特点。即使在恶劣的环境中，其精密加工的组件也能确保在更长的使用寿命内实现可靠的连接。无论是国防电子、航空航天还是工业控制系统，Twinax 连接器都能提供可靠的信号完整性。
特点和优势
- 双导体接口支持差分信号传输
- 出色的 EMI 和 RFI 屏蔽特性
- 结构坚固，适用于高可靠性应用
- 与各种电缆类型和配置兼容
- 具有高重复精度的安全配接接口
主要技术细节
- 提供多种配置，包括插头、插孔和适配器样式
- 设计用于双轴电缆类型
- 常用于 IBM 系统、军用航空电子设备和通信控制硬件中
- 可承受关键任务环境中的机械应力和振动
应用
- 航空航天和国防通信系统
- 测试和测量设备
- 工业自动化和控制系统
- 传统计算机和外围设备接口
- 安全抗噪的数据传输环境
请浏览我们提供的标准产品，如果需要定制解决方案，请联系我们讨论您的应用要求。
Specifications
Twinax Connectors
Electrical
| Impedance | Non-Constant (Can be used with 78 and 95 ohm twin conductor cables) |
| Frequency Range | DC - 200 MHz (DC - 500 MHz with Caution) |
| Voltage Rating |
|
|
Keyway Polarization
|
500 Volts Peak |
|
Contact Polarization
|
100 Volts Peak |
Environmental
| Temperature Range |
|
|
PTFE
|
−55°C to +85°C |
|
Copolymer of Styrene (Rexolite)
|
−45°C to +121°C |
Mechanical
| Mating Cycles | 500 Min |
| Coupling Mechanism | Threaded or Bayonet |
Note: These characteristics are typical and may not apply to all connectors.
Connector configurations may affect performance.
Interface Dimensions
Plug
Jack
