射频终端器
精确匹配终端，实现信号完整性和系统保护
概述
Amphenol RF 提供全面的射频端接器产品组合，设计用于电气端接射频端口并防止信号反射。通过精确匹配同轴电缆的浪涌阻抗，这些终端器有助于在各种频率和连接器类型中保持信号清晰度、减少功率损耗并保护敏感的系统组件。
我们的终端器采用串内和串间配置，具有所有行业标准射频连接器接口，包括 BNC、SMA、TNC、N 型、HD-BNC、RP-SMA、QMA、SMP、SMB、Mini-UHF、F 型、1.0/2.3 和 7-16。这些精密元件对于测试台、广播设备、电信基础设施和射频仪器来说至关重要。
特性和优势
- 全面的产品组合覆盖范围- 提供所有常用连接器类型的端子，确保与现有的射频测试装置和电缆组件无缝集成。
- 信号完整性保护- 精确匹配的阻抗可最大限度地减少反射，有助于保持低噪声和干净的信号路径。
- 功率和频率多功能性- 选件支持从直流到 GHz 的频率范围和额定功率，适合典型的实验室、广播和电信应用。
- 耐用的结构- 坚固的设计和连接器级材料确保了在无数次配接过程中可靠的机械和电气性能。
- 易用性- 提供插头和插孔两种样式，可选项包括用于拴系安全和快速部署的链条。
主要技术细节
- 阻抗：50 Ω 和 75 Ω 配置，与标准射频系统匹配。
- 频率范围：适用典型的连接器频率限制（例如，SMA 高达 ~18 GHz，BNC 高达 ~12 GHz，使用 12G 广播电缆），性能取决于电缆。
- 配接周期：因连接器系列而异，如 BNC 卡口式、SMA/TNC 螺纹式、SMP/SMPM 推入式；实际周期取决于连接器/电缆组合。
- 功率处理：标准终端器的功率可达 ~2W；N 型终端器支持更高的频率应用和中等功率。
- 结构机加工外壳，电镀处理经久耐用；部分型号可提供链式附件，便于安装。
应用
- 测试和测量：用作假负载，以端接网络分析仪、频谱分析仪和测试装置上的端口。
- 广播和视频用于 12 GHz 12G-SDI 视频线路的高频 BNC 端接器可防止反射和信号失真。
- 电信和无线基础设施：用于基站和 DAS 安装的 N 型和 7-16 型终端器。
- 元件评估：实验室鉴定放大器、滤波器和接收器的理想选择。
- 射频原型设计：快速连接选项支持快速迭代和灵活组装。
请浏览以上我们的标准射频终端器，如果您的系统需要定制阻抗、额定功率或环境规格，请联系我们的工程师，为您的应用开发量身定制的解决方案。
规格
| 参数 | 值/范围 |
| 阻抗 | 50 Ω 和 75 Ω 可选，以匹配系统阻抗 |
| 频率范围 | 取决于连接器（例如，使用广播电缆的 BNC 高达 ~12 GHz；SMA/TNC/N-Type 高达 ~18 GHz） |
| 配接周期 | 每种连接器类型：BNC（卡口）、SMA/TNC（螺纹）、SMP 等；实际周期因组装而异 |
| 温度范围 | 典型值为 -40 °C 至 +85 °C；可能因连接器样式和电缆类型而异 |
| 特殊功能 | 链式连接系绳选项；坚固的金属机身；系列内和系列间设计 |
