通过 IP67 RP-TNC 防水连接器增加连接选项

Amphenol RF provides comprehensive custom RF solutions tailored to meet specific design requirements, from concept through mass production.

Amphenol RF's IP67 SMA Bulkhead Cable Assemblies feature pre-configured 50 ohm assemblies on flexible RG-316 coaxial cable, designed for both indoor and outdoor applications. These assemblies, available in various lengths, offer secure locking with threaded connectors, providing reliable performance up to 3 GHz, and are ideal for industrial equipment, antennas, and military communications.

Amphenol RF's Harsh Environment Solutions provide a range of rugged, IP67/68 waterproof, and tamper-resistant connectors and cable assemblies designed for challenging conditions, ensuring system safety and performance. These products are suitable for applications such as smart agriculture, industrial machinery, outdoor security systems, and mining equipment, with specialized options available for various standard product series.

Amphenol RF's Harsh Environment Solutions provide a range of rugged, IP67/68 waterproof, and tamper-resistant connectors and cable assemblies designed for challenging conditions, ensuring system safety and performance. These products are suitable for applications such as smart agriculture, industrial machinery, outdoor security systems, and mining equipment, with specialized options available for various standard product series.

Amphenol RF offers black-plated RF interconnect solutions featuring a durable, non-reflective black zinc cobalt coating that is RoHS and REACH compliant. These connectors and adapters are designed for harsh environments, providing up to 48 hours of salt spray endurance for corrosion resistance. Suitable for military and covert applications, they maintain excellent RF performance and conductivity. Applications include field communication arrays, handheld military/law enforcement radios, portable radar, precision positioning systems, and surveillance equipment. Waterproof IP67 configurations are also available for enhanced protection.

Amphenol RF presents a comprehensive, high-performance portfolio of RF interconnect solutions, engineered to meet the rigorous demands of modern communications and electronic systems across industries. With decades of leadership in coaxial technology, this catalog showcases cutting-edge product lines, each designed for precision, reliability, and adaptability.

The Amphenol 2003 Full Line Catalog features a comprehensive range of connectors, including subminiature (MMCX, MCX, 1.0/2.3, SMB, SMC, SMA), miniature (BNC, TNC, Reverse Polarity), and standard types (Twinaxial, Twin BNC, Triax, UHF, Mini-UHF). Each section provides detailed specifications, available configurations, and applications for various industries, such as telecommunications, instrumentation, military, and industrial use. The catalog also includes cable assembly instructions and a glossary for additional support.

The Amphenol 2006 Full Line Catalog includes a comprehensive range of connectors and cable assemblies for various applications. The catalog also covers environmental compliance and quality assurance measures, showcasing Amphenol's commitment to reliable and high-performance interconnect solutions.

The Amphenol Connex Catalog features a comprehensive range of high-quality RF and microwave coaxial connectors, suitable for various applications including instrumentation, military-aerospace, broadband, RFID, and telecommunications. It offers a wide selection of connectors such as MMCX, MCX, SMA, SMB, BNC, TNC, UHF, and 7/16, along with custom cable assemblies and robust technical support​​.

The Amphenol RF 2.2-5 Product Data Sheet highlights the 2.2-5 connector series, designed for high-performance RF applications requiring compact size, low PIM, and superior electrical performance. This connector series is engineered to support high-frequency, low-loss signal transmission, making it ideal for 5G networks, small cells, and distributed antenna systems (DAS). With a rugged, weatherproof design, these connectors ensure reliable performance in harsh environments while maintaining ease of installation through various coupling mechanisms, including threaded, push-pull, and hand-screw options.

The 4.3-10 Connector Cut Sheet provides a detailed overview of the 4.3-10 RF connector series, designed for superior performance in high-frequency applications. This document outlines the key features of the 4.3-10 connectors, including their low PIM (Passive Intermodulation) performance, compact design, and high durability, making them ideal for telecommunications, wireless infrastructure, and RF signal transmission. The connectors are engineered for easy installation, offering a user-friendly interface with threaded, push-pull, and hand-screw coupling mechanisms to ensure secure connections.

Amphenol RF's 18 GHz N-Type connectors extend the frequency range of the traditional N-Type product line to 18 GHz, providing excellent low PIM performance in a durable, medium-sized package. These connectors are ideal for rugged, outdoor applications requiring high power handling and vibration resistance, with applications in microwave, wireless infrastructure, and radar systems.

The Amphenol RF FAKRA to AMC Cable Assemblies datasheet highlights fixed-length assemblies designed for automotive and IoT applications. These IP67-rated assemblies combine FAKRA connectors with micro-miniature AMC connectors on 1.37 mm ultra-flexible coax cable, providing compact and sealed solutions ideal for DSRC, V2X, V2V technologies, 360-degree cameras, ADAS, smart boxes, and remote control access​​.

Amphenol Micro Coaxial (AMC) connectors are low-profile solutions with a 2.5mm mating height and a 3mm x 3mm footprint, designed for portable and mobile devices. These connectors support high-frequency transmission from DC to 6 GHz, feature easy snap-on/off mating, and are compatible with Hirose U.FL and IPEX MHF1 series, making them ideal for applications like antennas, Bluetooth, GPS, WLAN, and cellular devices.

The Field Installable N-Type Connector Cut Sheet presents a high-performance N-Type connector designed for quick and efficient field installation without requiring special tools. Engineered for low-loss, high-frequency applications, this connector ensures secure and reliable RF connections in demanding environments. It features a rugged, weatherproof design, making it ideal for outdoor and industrial use, while its low PIM (Passive Intermodulation) performance supports high-quality signal integrity.

The Amphenol RF PSMP Cut Sheet highlights the PSMP connector series, a versatile RF solution engineered for high-power applications requiring robust performance and flexibility. This series is designed to handle high-frequency signals with excellent electrical performance, making it ideal for base stations, power amplifiers, and industrial applications. The PSMP connectors feature a compact, high-reliability design with options for smooth bore and full detent mating styles, ensuring secure connections while accommodating misalignment.

Amphenol Micro Miniature Coaxial (AMMC) connectors are designed for portable and mobile devices, featuring a low profile with a 1.4 mm mated height and a 2 mm x 2 mm footprint. These connectors support high-frequency transmission from DC to 6 GHz, offer easy snap-on/off mating, and are compatible with Hirose W.FL and IPEX MHF III series, making them ideal for applications such as antennas, Bluetooth, GPS, WLAN, and cellular devices.

The HD-EFI product series by Amphenol RF offers micro-miniature interfaces designed for high-performance applications with a frequency range from DC to 6 GHz. These 50 ohm products are ideal for board-to-board applications, featuring versatile PCB mounts and bullet lengths, and providing up to 1.4 mm axial and radial float. HD-EFI connectors are available in various configurations, including through-hole, surface mount, edge launch, and thread-in, and support blind mating with crash-proof designs​​.

The "Sealed FAKRA Cut Sheet" highlights FAKRA/USCAR mechanical coding for connectors. These connectors are designed for secure and reliable automotive applications, featuring mechanical and color coding to prevent mismating. The sealed FAKRA connectors are IP67 rated, providing protection against dust and temporary submersion in water, making them ideal for use in harsh environments​​.

The "Connectors Optimized for Low Loss Cables" guide by Amphenol RF features redesigned SMA, TNC, and N-Type connectors specifically tailored for Low Loss cables. These connectors, which include straight and right-angle plugs and jacks, provide enhanced shielding, improved grounding, and low signal loss for applications requiring high reliability, such as smart city infrastructure and IoT antenna systems. They support frequencies up to 12.4 GHz for SMA and 6 GHz for TNC and N-Type connectors, ensuring consistent electrical performance and quick, secure assembly with standard hex crimp tooling​​.

The Amphenol RF SMA Panel Mount Receptacles cut sheet details high-performance connectors supporting frequencies from DC to 18 GHz. These stainless steel receptacles are available in multiple panel mounting configurations, including 2 and 4-hole flanges, with various termination options such as post contacts, solder cups, and tab contacts. The connectors are suitable for applications like RF amplifiers, microwave filters, and power dividers, offering excellent VSWR performance and robust mechanical construction​​.

The document on ingress protection ratings explains the IP (Ingress Protection) standard, detailing the levels of protection provided by electrical connectors against foreign materials like dust and water. IP67, for example, signifies that the connector is dust-tight (6) and protected against the effects of temporary submersion in water up to 1 meter for 30 minutes (7). These ratings ensure that connectors are suitable for various environments by providing specific resistance to both solid particles and moisture​​.

The Amphenol Connex Cable Connector Guide provides an extensive selection of RF connectors and adapters, detailing common parts for popular cable types. The guide emphasizes uncompromised quality, vast selection, and superb technical support, while also offering customization options for specific customer needs. It includes information on crimp tooling compatible with industry-standard crimp die set dimensions, ensuring reliable and efficient assembly​​.

The Amphenol RF AUTOMATE Type A Mini-FAKRA connector series offers a high-performance, space-efficient solution for automotive applications, supporting data transmission up to 20 Gbps. These connectors feature a compact, modular housing that saves up to 80% installation space compared to traditional FAKRA connectors and are available in single, dual, and quad-port configurations. They are ideal for applications such as 360-degree surround view cameras, ADAS, GPS navigation, high-bandwidth infotainment, and V2X communication. The connectors provide low engagement and disengagement forces, impact resistance, and visual guidance through color-coded housings to prevent mis-mating.

The Amphenol RF TNC Plug-to-Plug Cable Assemblies datasheet describes 50 ohm assemblies available in standard lengths from six inches to four meters, featuring threaded coupling for secure and stable connections. These high-performance assemblies, suitable for industrial connectivity and external antennas, operate up to 11 GHz and come in ruggedized and IP67 options​​.

The Amphenol RF IP67 HD-BNC Product Series features waterproof HD-BNC connectors designed for high-density applications that require protection against environmental elements. These connectors are 75% smaller than traditional BNC connectors, offer a bayonet-style positive lock mechanism, and are available in both 50 and 75 ohm configurations, making them ideal for high-definition cameras, military radios, broadcast studios, and remote industrial equipment.

Amphenol RF's IP67 TNC connectors are waterproof and tamper-resistant, featuring a threaded coupling mechanism for secure mating. These 50 ohm connectors are designed for applications in antennas, industrial, wireless, military, and broadband sectors, offering durable construction and reliable performance up to 11 GHz, with various configurations available including front and rear-mounted bulkhead jacks.

The Amphenol RF TNCRP-TNC Ultraminiature Cable Assemblies datasheet features 50 ohm assemblies on micro-coax cables, designed for space-constrained applications like IoT infrastructure and consumer devices. These assemblies offer secure mating, weatherproof and tamper-resistant options, and flexible routing within enclosures, supporting frequencies up to 18 GHz and available in standard lengths from 50 to 300 millimeters​​.

Amphenol RF's IP67 SMA Front Mount Bulkhead Jacks offer waterproof, tamper-resistant RF interconnect solutions with reliable electrical performance up to 6 GHz. Designed for applications like antennas, base stations, and industrial automation, these connectors feature a threaded coupling mechanism for secure mating and are ideal for use in space-constrained environments.

Amphenol RF's IP67 RP-TNC connectors are waterproof, tamper-resistant, and feature a threaded coupling mechanism for secure and stable mating. Designed for applications in antennas, industrial, wireless, military, and broadband sectors, these 50 ohm connectors offer a variety of configurations, including front and rear-mounted bulkhead jacks, and operate up to 11 GHz.

Amphenol RF's Ruggedized BNC & TNC Cable Assemblies feature IP67 sealed 50 ohm connectors on RG-58 cable, with BNC's quick bayonet coupling and TNC's threaded coupling for stable performance. These assemblies are ideal for industrial, military, and commercial applications, available in standard lengths from 6 inches to 100 feet, with optional PVC armor for enhanced protection in rough environments.

Amphenol RF's Locking MHF I Cable Assemblies feature a patented locking system for tamper-resistant, vibration-resistant performance, available with waterproof IP67 options. These 50 ohm assemblies are ideal for applications such as drones, GPS, and industrial automation, offering reliable electrical performance up to 6 GHz with configurations including SMA, RP-SMA, TNC, and RP-TNC connectors.

The Amphenol RF Maritime Solutions Overview highlights RF interconnect solutions designed for marine applications. It showcases durable, high-performance connectors and cable assemblies that ensure reliable signal transmission in harsh maritime environments, supporting navigation, communication, and radar systems.

Amphenol RF's FAKRA rear mount bulkhead crimp plugs are engineered for automotive and industrial applications, supporting TFC 302LL and RG-174 cables. These connectors provide reliable electrical performance up to 6 GHz, feature IP67-rated waterproofing, and are available in various color-coded key codes for easy installation.

The Amphenol RF Locking MHF 4 Ultraminiature Cable Assemblies datasheet describes pre-configured, vibration-resistant 50-ohm cable assemblies featuring the I-PEX MHF® 4 LK locking connector. These ultraminiature assemblies are designed with tamper-resistant, waterproof (IP67) options and utilize 1.37 mm micro-coax cable paired with SMA or RP-SMA connectors for reliable electrical performance in rugged environments. Ideal for continuous shock and vibration applications, they are used in UAVs, IoT devices, military systems, smart agricultural equipment, and communication networks. The datasheet also outlines available standard lengths (50–400 mm) and key specifications, including a frequency range up to 9 GHz, 500 mating cycles minimum, and materials such as gold-plated brass and PTFE insulation.

The Amphenol RF MCX Cable Assemblies Data Sheet highlights between-series board-to-panel cable solutions designed for wireless communication modules. These assemblies combine compact MCX interfaces with rugged, sealed bulkhead connectors to enable reliable RF connectivity in space-constrained and environmentally exposed applications.

The Amphenol RF MMCX cable assemblies datasheet outlines pre-configured 50-ohm RF cable solutions using flexible RG-174 coax for reliable connections in wireless communication modules. It highlights available connector configurations, electrical performance characteristics, and suitability for applications such as IoT, GPS, Wi-Fi, and other compact RF systems.

Discover how Amphenol RF’s AUTOMATE® Mini-FAKRA connecters and cable assemblies offer reliable, high-performance connectivity for automotive and industrial applications. In this video, we explore the features of our standard mini-FAKRA solutions and dive into the custom engineering capabilities that set us apart. Whether you need unique configurations, specialized materials or enhanced performance for harsh environments, our global team of engineers can design a solution tailored to your exact design specifications. From compact, modular housing to flexible cable options, Amphenol RF delivers high-quality FAKRA solutions for your most demanding applications. Learn how our expertise can power your next project! Don’t forget to subscribe for more insights into our advanced RF interconnects and custom-engineered solutions. AUTOMATE® Product Catalog: https://www.amphenolrf.com/library/download/link/link_id/600297/ Check us out on social media: https://www.facebook.com/officialAmphenolRF https://www.linkedin.com/company/amphenol-rf/mycompany/ https://www.twitter.com/AmphenolRF Our Website: https://www.amphenolrf.com

In this video, we had one of our engineers give a step-by-step tutorial on how to install a coaxial connector (TNC) on an RG-58 cable. This engineer is following our 3 Pc Crimp - Crimp instructions which you can find in the link below, free to download. Download the 3 Pc Crimp - Crimp assembly instructions here: https://www.amphenolrf.com/031-2367-rfx.html For Additional connector instructions: https://www.amphenolrf.com/rf-connector-assembly-instructions Check us out on social media: www.facebook.com/officialAmphenolRF www.linkedin.com/company/amphenol-rf/mycompany/ https://twitter.com/AmphenolRF

AUTOMATE Mini-FAKRA connectors are revolutionizing cable assemblies with their compact design and robust performance. In this short, we summarize what makes AUTOMATE mini-FAKRA connectors unique, how they’re used in automotive, industrial, and other high-tech applications, and why they’re crucial for today’s advanced connectivity needs. Perfect for tech enthusiasts, engineers, and anyone curious about high-performance cable assemblies! View these products on our website: https://www.amphenolrf.com/rf-cable-assemblies/automate-type-a-cable-assemblies.html Check us out on social media: https://www.facebook.com/officialAmphenolRF https://www.linkedin.com/company/amphenol-rf/mycompany/ https://www.twitter.com/AmphenolRF Our Website: https://www.amphenolrf.com

View full article: https://www.allaboutcircuits.com/new-industry-products/amphenol-rf-connectors-for-low-loss-cables-tech-specs/ Amphenol RF offers SMA, TNC, and N-Type connectors that have been redesigned and optimized for use with low loss cabling. They offer improved grounding, enhanced shielding, and low return loss from DC to 6GHz. The connectors are available in straight jack, bulkhead jack, straight plug, and right-angle plug configurations, with options for 195, 240, and 400 series low loss cable. For more information, as well as all the latest All About Circuits projects and articles, visit the official website at http://www.allaboutcircuits.com/ Check out TTI, INC's profile on All About Circuits and see more technical articles they created at https://www.allaboutcircuits.com/author/tti-inc TTI, Inc's website: https://www.ttiinc.com/content/ttiinc/en.html Don't have AAC account yet? Register here! It's free and always will be. https://forum.allaboutcircuits.com/register Subscribe on YouTube: https://www.youtube.com/c/AllAboutCircuitsVideo Like us on Facebook: https://www.facebook.com/allaboutcircuits Follow us on Twitter: https://twitter.com/AllAboutCircuit Follow us on LinkedIn: https://www.linkedin.com/company/allaboutcircuits

View full article:https://www.allaboutcircuits.com/tech-chats/ruggedized-ip67-rf-connector-solutions-tech-chat-amphenol-rf-with-mouser-electronics/ Tech Chats is a video series highlighting long-form conversations with industry experts about the features, applications, and technical specs of newly-released products. For more information, as well as all the latest All About Circuits projects and articles, visit the official website at http://www.allaboutcircuits.com/ Check out Mouser's profile on All About Circuits and see more product briefs and articles at https://www.allaboutcircuits.com/author/mouser-electronics For more new products at Mouser, visit https://www.mouser.com/new/ Register on AAC: https://forum.allaboutcircuits.com/register Subscribe on YouTube: https://www.youtube.com/c/AllAboutCircuitsVideo Like us on Facebook: https://www.facebook.com/allaboutcircuits Follow us on Twitter: https://twitter.com/AllAboutCircuit Follow us on LinkedIn: https://www.linkedin.com/company/allaboutcircuits
