产品规格
参见模拟
产品规格
| 属性 | 详细信息 |
参见模拟
选择以下属性查看类似产品
|
|---|---|---|
| Adapter Configuration |
SMPM plug to SMP Plug
|
|
| Adapter Type |
In-Series
|
|
| Body Finish |
Gold
|
|
| Body Material |
Beryllium Copper
|
|
| Contact Finish |
Gold
|
|
| Contact Material |
Beryllium Copper
|
|
| Country of Origin |
CN
|
|
| ECCN |
EAR99
|
|
| HTS Code |
8536.69.4010
|
|
| Impedance (Ohms) |
50
|
|
| Insulator Material |
PTFE
|
|
| IP Rating |
Not Rated
|
|
| Isolated |
No
|
|
| Low PIM |
No
|
|
| Mil Qualified |
Not Mil Qualified
|
|
| Non Magnetic |
Contains Magnetic Materials
|
|
| Orientation |
Straight
|
|
| PFAS |
Contains PFAS
|
|
| Temp (Max Degrees Celsius) |
165
|
|
| Temp (Min Degrees Celsius) |
-65
|
|
| Unit Weight (Grams) |
0.220
|
|
| USMCA Compliant |
Not USMCA Compliant
|
|
