射频开关连接器
在紧凑型板级射频解决方案中内置测试接入和信号路由功能
概述
Amphenol RF 的射频开关连接器为测试射频电路提供了一种坚固耐用、经济高效的方法，无需物理断开和重新连接电缆。这些连接器集成了机械开关功能，允许信号在正常工作时保持连续，并在测试过程中重新定向信号。
射频开关连接器设计经久耐用，使用方便，有多种行业标准接口（如 SMA 和 MCX）可供选择。它们非常适合紧凑型环境中的 PCB 安装设计，在这种环境中，保持信号完整性和最大限度地利用电路板空间至关重要。
特点和优点
- 集成开关功能，无需外部开关硬件
- 紧凑型 PCB 安装设计优化了有限的电路板空间
- 提供SMA 和 MCX 等常用接口，实现无缝设计集成
- 耐用的结构支持多次测试周期
- 实现非侵入式测试，提高可靠性并减少电缆磨损
主要技术细节
- 提供 50 欧姆配置
- 频率支持高达 6 GHz（取决于电缆和 PCB）
- 专为标准电路板到仪器的信号接入而设计
- 开关功能可重复测试周期
- PCB 安装设计，具有安全的通孔或表面贴装基底面
应用
- 射频设备生产测试
- 无线模块验证
- 便携式射频仪器
- 物联网和消费电子产品诊断
- 天线开关模块
浏览我们的标准射频开关连接器选件，以简化测试集成。如果您的应用需要定制 PCB 布局、频率支持或开关功能，请联系我们，我们将为您提供量身定制的设计支持。
Specifications
4.3/10 Connectors
Electrical
| Impedance | 50 Ω |
| Frequency Range | DC to 6 GHz |
| Voltage Rating | X Volts RMS Continuous |
| Dielectric Withstanding Voltage | X VRMS Max |
| VSWR | XX (X.XX dB) |
| DC - X GHz | XX (X.XX dB) |
| X - Y GHz | XX (X.XX dB) |
| Y - Z GHz | XX (X.XX dB) |
| Insulation Resistance | XXXX MΩ min |
| Contact Resistance | |
| Center Contact | X.X mΩ Min |
| Outer Contact | X.X mΩ Min |
| RF Leakage | -XX dB Min |
| Insertion Loss | XX dB Max |
| Passive Intermodulation (PIM) | XX dBc with 2 X 43 dBm inputs |
| Power Handling | XX W @ XX GHz @ XX ºC |
Environmental
| Temperature Range | −55 to +90 °C |
| Thermal Shock | MIL-STD-202… |
| Corrosion | MIL-STD-202… |
| Vibration | MIL-STD-202… |
| Mechanical Shock | MIL-STD-202… |
| Moisture Resistance | MIL-STD-202… |
| Altitude | MIL-STD-202… |
Mechanical
| Mating Cycles | XXX Min |
| Coupling Mechanism | |
| Interface Specification | MIL-STD-348 |
| Engagement Force
|
XX lbs (XX N) |
| Disengagement Force | XX lbs (XX N) |
| Mating Torque, Min Working
|
inch-pounds |
| Mechanical Misalignment | |
| Axial | |
| Radial | |
| Max Float Angle | |
| Min Board to Board Distance | XX mm |
Note: These characteristics are typical and may not apply to all connectors.
Connector configurations may affect performance.
Interface Dimensions
Plug
Jack
