安费诺射频公司欣然推出一款专为柔性1.13毫米微同轴电缆设计的防篡改BNC隔板插座。这款面板安装式连接器经工程优化，可在高达9 GHz频率下提供强劲可靠性，以支持Wi-Fi 7技术。该BNC连接器特别适用于测试测量、电信及工业应用场景。
新型BNC隔板插座采用镀镍黄铜主体与镀金铍铜触点，这些材料能承受恶劣环境，确保信号完整性与高频性能始终如一。轻量化设计使其成为空间受限应用的理想选择。
适用于微同轴电缆的BNC连接器系列，作为标准解决方案纳入不断扩充的射频互连产品目录。
查看全部：BNC舱壁插座
