Assembly Instructions

RF Connectors featuring a clamp design are often field installable with minimal tooling. Connectors are secured to a cable using a clamp design that sandwiches the cable's braid between two components that compress when assembled. If you’re assembling a Clamp Connector Assembly, the following instructions may apply:

Crimp connectors feature a ferrule that crimps onto a cable's braid. The connector's center contact can sometimes be crimped into the center conductor or soldering may be required. If you need to purchase crimp tooling including crimp frames and die sets, please visit our Tools Category Page. If you're assembling a crimp connector, the following assembly instructions may apply:

Semi-rigid (or hand-formable) cable types offer durable, ruggedized construction and are engineered with a solid outer shield. They are often stiffer than other coaxial cables and require bending tools for more flexibility. Hand-formable cable types are flexible, malleable alternatives to more rigid coaxial cables. They can be formed by hand without any special tools required. If you’re assembling a Solder Connector Assembly, the following instructions may apply.
