1.0-2.3 Adapters
Compact coaxial adapters for seamless RF transitions between 1.0-2.3 and other standard interfaces including BNC, SMA, N-Type, and HD-BNC.
Overview
Amphenol RF’s 1.0-2.3 adapters are designed to support high-density, high-performance RF applications where space savings and signal integrity are critical. These compact DIN-style adapters offer reliable in-series and between-series conversions in both 50 ohm and 75 ohm configurations, ideal for broadcast, instrumentation, and telecommunication systems.
Available in a variety of straight and bulkhead designs, these adapters feature precision-machined components and durable plated finishes to ensure consistent electrical performance up to 10 GHz. The 1.0-2.3 interface allows engineers to maximize panel space without sacrificing signal quality, and is commonly used in conjunction with BNC, SMA, and N-Type connectors across high-frequency applications.
Features and Benefits
-
In-series and between-series configurations with BNC, SMA, N-Type, and HD-BNC interfaces.
- Available in 50 Ω and 75 Ω versions for standard and broadcast-specific needs.
- Compact design supports dense RF layouts and front-panel installations.
- Bulkhead and panel-mount options enable secure integration into equipment housings.
- Rated up to 10 GHz depending on configuration and connector pairing.
Applications
-
Broadcast Video Equipment – Compact, high-frequency transitions for 75 ohm video systems.
- Test and Measurement – Connector saver and bulkhead adapters for instrument integration.
- Telecom Infrastructure – High-density RF signal routing in panel and rack-mounted hardware.
- Industrial and Embedded Systems – Secure, space-saving RF transitions for compact electronic assemblies.
Related Resources
High Density Broadcast Solutions
The "High-Density Broadcast Solutions" document from Amphenol RF highlights their range of RF interconnects designed for broadcast connectivity, including BNC, Mini-BNC, 1.0/2.3 DIN, and HD-BNC connectors. These connectors offer various impedances and frequency ranges, with HD-BNC providing the highest density at an 8mm pitch and supporting data rates up to 12 Gb/s. Applications include high-definition transmission, video routing, mobile broadcast equipment, and digital signage, ensuring reliable performance and reduced equipment size without compromising signal integrity.
White Paper: High Density Interconnect Standards
The "High Density Interconnect Standards for Next Generation Broadcast Networks" paper discusses the HD-BNC connector, designed to meet modern broadcast systems' demands for higher density and performance. HD-BNC offers significant density improvements over traditional BNC connectors, with a 75 ohm interface optimized for high bandwidth up to 6 GHz. It maintains robustness and user-friendly bayonet-style mating, providing better mechanical and RF performance than other high-density alternatives like 1.0/2.3 and Mini-BNC. The HD-BNC's design ensures compatibility with industry-standard tools and cables, making it a superior choice for next-generation broadcast applications.
RF Interconnect for 12G-SDI Broadcast Applications -- Amphenol RF and Mouser Electronics
September 23, 2020 - Today’s 4K and emerging 8K video standards require an enormous amount of bandwidth. And, with all that bandwidth, there are new demands on our interconnects. In this episode of Chalk Talk, Amelia Dalton chats with Mike Comer and Ron Orban of Amphenol RF about the evolution of broadcast technology and the latest interconnect solutions that are required to meet these new demands.
More information about Amphenol RF Adapters & Cable Assemblies for Broadcast: https://bit.ly/3iYYECS
