7-16 Adapters
Durable, high-power RF adapters designed for reliable low-PIM performance in demanding telecom and broadcast environments.
Overview
Amphenol RF’s 7‑16 adapters are engineered to support high-performance RF connectivity in infrastructure applications that require low passive intermodulation (PIM), high power handling, and secure, threaded mating. These adapters offer both in-series and between-series configurations to transition between 7‑16 and other common interfaces such as N-Type, 4.3‑10, 2.2‑5, and 4.1‑9.5.
Built with robust materials and precision-machined components, 7‑16 adapters ensure excellent mechanical stability and consistent electrical performance. Many configurations include bulkhead or flange mounting options for secure panel integration, and select models are rated IP67 for use in harsh or outdoor conditions. These adapters are ideal for modern wireless infrastructure and test environments.
Features and Benefits
- Low PIM performance for high-reliability, high-power RF systems.
- In-series and between-series options including 7‑16 to N-Type, 4.3‑10, 2.2‑5, and 4.1‑9.5.
- Rugged threaded coupling ensures stable electrical connection in high-vibration settings.
- Available with bulkhead and flange mounting for easy chassis integration.
- Select IP67-rated designs for outdoor and sealed applications.
Applications
- Telecom Infrastructure – Base stations, antennas, and DAS systems.
- Broadcast Systems – High-power RF links requiring robust, low-loss interconnects.
- Outdoor Equipment – IP67-rated options for sealed panel installations.
- Test and Measurement – Connector savers and interface adapters for lab environments.
- Industrial RF Systems – Reliable threaded solutions for high-vibration, mission-critical deployments.
