MCX Adapters
Compact snap‑on MCX adapters providing quick, reliable 50 Ω and 75 Ω transitions for high-frequency RF systems.
Overview
.jpg)
Amphenol RF offers a complete range of MCX adapters, including in-series MCX‑to‑MCX barrels and between-series adapters to SMA, BNC, TNC, N‑Type, HD‑BNC, and more. Designed for field serviceability, these connectors enable swift mating and gender conversion in miniature RF setups.
Ideal for automotive, broadband, instrumentation, and IoT applications, MCX adapters maintain performance up to 6 GHz, with select 75 Ω versions suitable for broadcast paths. Their snap‑on coupling and compact footprint make them perfect where space is constrained and reliability is critical.
Features and Benefits
- Snap‑On Quick‑Connect Design – Enables fast, tool‑free mating & unmating, perfect for compact devices.
- Full 50 Ω & 75 Ω Support – Includes industry-standard connectors and optimized paths for broadcast and data.
- Space‑Saving Miniature Form Factor – Outer diameter ~3.6 mm, ~30% smaller than SMB connectors.
- Connector Saver Use – Protects cables and instrumentation ports by serving as sacrificial adapters.
Applications
- Automotive & IoT Devices – Micro antenna and sensor interfaces in space-constrained modules.
- Broadband & Broadcast – 75 Ω MCX adapters facilitate HDTV and streaming system integrations.
- Test & Instrumentation – Inline MCX adapters used to protect RF test equipment and allow gender conversion.
- Wireless Infrastructure – Compact snap‑on MCX for RF boards in WLAN, GPS, and base-station modules.
