SMC Adapters

Amphenol RF’s SMC Adapters provide robust and flexible connectivity for RF applications where space constraints and dependable performance are critical. These subminiature adapters feature a threaded coupling mechanism for vibration resistance, making them suitable for semi-permanent connections in compact and portable devices. Available in both in-series and between-series configurations, SMC adapters support seamless integration between different RF interfaces.

Engineered for DC to mid-frequency applications, SMC adapters are used across a variety of industries including test and measurement, telecommunications, and GPS systems. Their compact size, combined with consistent electrical performance, makes them ideal for designs requiring a durable and space-saving interconnect solution.

Features and Benefits

• Threaded coupling ensures secure and vibration-resistant connections
• Available in in-series and between-series configurations for design flexibility
• Compact footprint supports high-density applications
• Reliable performance from DC up to 4 GHz

Key Technical Details

• 50 Ω impedance for standard RF applications
• Brass and beryllium copper materials with gold plating for corrosion resistance and durability
• Supports DC to 4 GHz depending on configuration
• Compatible with multiple RF series via between-series adapters

Applications

• GPS Systems – Provide reliable signal interconnects in compact navigation electronics.
• Telecommunication Equipment – Used in signal routing within small form factor infrastructure hardware.
• Test and Measurement Devices – Enable compact and stable interconnects in RF test setups.
• Consumer Electronics – Support RF functionality in tightly integrated electronic assemblies.
