AMC Cable Assemblies
Ultra-miniature RF cable assemblies for compact wireless and embedded designs
Overview
Amphenol RF’s AMC cable assemblies are designed to address the evolving needs of compact wireless and embedded systems. Featuring the ultra-miniature AMC connector interface and compatible with micro coaxial cables such as 0.81 mm and 1.13 mm, these assemblies support frequencies up to 6 GHz and are hi-pot and continuity tested for quality assurance. Select assemblies may also support frequencies above 6 GHz to enable next-generation technologies such as Wi-Fi 7, depending on configuration.
These lightweight, low-profile solutions are ideal for space-constrained environments, offering a secure snap-on connection in applications such as IoT modules, wearables, and industrial sensors. AMC cable assemblies are available in a variety of lengths and orientations and feature compatibility with Hirose® U.FL and I-PEX® MHF® I and MHF® I LK connector systems*, ensuring seamless integration with standard board-mount solutions. IP67-sealed options are also available for environments requiring environmental protection.
Features and Benefits
- Ultra-miniature form factor ideal for high-density designs
- Frequency performance up to 6 GHz; certain assemblies support higher frequencies for Wi-Fi 7 applications
- Snap-on mating interface ensures secure, tool-less connection
- Compatible with micro coaxial cable types: 0.81 mm, 1.13 mm, 1.32 mm, and 1.37 mm
- Cable mount connectors available in right-angle only
- IP67-sealed options available for environmental sealing
- Designed to mate with Hirose® U.FL and I-PEX® MHF® I and MHF® I LK connector systems*
- Hi-pot and continuity tested for enhanced product reliability
Key Technical Details
- Connector Series: AMC (Amphenol Micro Coaxial)
- Coupling Mechanism: Snap-on interface
- Cable Mount Orientation: Right-angle only
- Cable Types Supported: Micro coaxial (e.g., 0.81 mm, 1.13 mm, 1.32 mm, 1.37 mm)
- Testing Method: Hi-pot and continuity tested on all standard assemblies
- Advanced Configurations: Select assemblies capable of frequencies above 6 GHz for Wi-Fi 7 compatibility
Applications
AMC cable assemblies are engineered for:
- IoT sensors and communication modules
- Wearable medical and fitness devices
- Embedded wireless systems
- Consumer electronics and mobile platforms
- Industrial sensors and control systems
- Wi-Fi, Bluetooth®, and GPS-enabled devices
- UAVs, robotics, and compact antennas
Explore our broad selection of standard AMC cable assemblies or contact our team of RF experts to develop a custom configuration tailored to your application.
