AMC4 Cable Assemblies
Ultra-miniature RF cable assemblies with enhanced durability for compact wireless applications
Overview
AMC4 cable assemblies from Amphenol RF are an evolution of the popular AMC interface, designed to support RF applications that require ultra-compact form factors along with greater mechanical stability. Featuring the AMC4 connector series and compatible with micro coaxial cables such as 0.81 mm and 1.13 mm, these assemblies provide reliable performance up to 6 GHz and, in some cases, support higher frequencies to enable Wi-Fi 7 functionality.
These assemblies are offered in right-angle plug configurations and terminated to micro coax cable, allowing seamless integration into high-density designs such as IoT modules, wearables, and embedded wireless systems. AMC4 cable assemblies are hi-pot and continuity tested, and select versions offer IP67 sealing for environmental protection. This series is engineered to meet the stringent mechanical and electrical requirements of compact, high-frequency RF applications.
Features and Benefits
- Ultra-miniature design for high-density, low-profile system layouts
- Robust interface supports frequency ranges up to 6 GHz and beyond in select assemblies
- Right-angle cable mount connectors for streamlined internal routing
- Terminated to standard micro coax cable types: 0.81 mm, 1.13 mm, and 1.37 mm
- Secure snap-on mating interface for ease of installation
- IP67-sealed variants available for added protection in harsh environments
- Hi-pot and continuity tested to ensure consistent electrical performance
Key Technical Details
- Connector Series: AMC4 (Amphenol Micro Coaxial, Gen 4)
- Mating Style: Snap-on connection
- Cable Mount Orientation: Right-angle only (straight version not available)
- Cable Types: Micro coaxial cables including 0.81 mm, 1.13 mm, 1.37 mm
- Testing: All standard assemblies are hi-pot and continuity tested
- Frequency Support: Up to 6 GHz; some configurations capable of supporting Wi-Fi 7 (above 6 GHz)
Applications
AMC4 cable assemblies are ideal for:
- IoT sensors and gateways
- Smart wearables and compact medical devices
- GPS and wireless communication modules
- Embedded computing and system-on-module (SoM) architectures
- Industrial automation and control interfaces
- Robotics, UAVs, and compact antenna solutions
Browse our range of standard AMC4 cable assemblies to find the right fit for your application. Need something unique? Contact our RF experts to create a custom assembly tailored to your specifications.
All AMC4 Cable Assembly Categories
