AUTOMATE Type A Cable Assemblies
High-density, automotive-grade RF assemblies built for advanced driver-assistance and infotainment systems
Overview
Amphenol RF’s AUTOMATE Mini-FAKRA Type A cable assemblies are engineered to support the growing data and signal demands of modern automotive systems. These assemblies feature compact Mini-FAKRA Type A connectors terminated to low-loss coaxial cable, providing reliable performance up to 9 GHz. Built to industry-standard USCAR-2 and designed with automotive-grade materials, these solutions are ideal for ADAS, infotainment, and V2X communications.
The Mini-FAKRA Type A interface enables up to 80% space savings over traditional FAKRA connectors, supporting higher circuit densities in constrained vehicle architectures. Each assembly is color-coded and keyed to ensure proper mating and prevent misconnection. All standard AUTOMATE assemblies are hi-pot and continuity tested, and IP67-sealed options are available for harsh or outdoor environments. These cable assemblies support the evolution of autonomous driving and connected vehicle infrastructure.
Features and Benefits
- Miniature automotive-grade RF solution with up to 80% space savings
- Performance up to 9 GHz with low-loss cable options
- Color-coded and keyed interfaces ensure correct and secure mating
- Complies with automotive industry standards including USCAR-2
- Available in straight and right-angle configurations
- Hi-pot and continuity tested for production reliability
- IP67-sealed variants available for protection against dust and moisture
- Designed for high-density, high-data-rate in-vehicle networks
Key Technical Details
- Connector Series: AUTOMATE Mini-FAKRA Type A
- Standard Compliance: USCAR-2, FAKRA MINI automotive standards
- Cable Types Supported: Low-loss coaxial cables (varies by part number)
- Orientation Options: Straight and right-angle plug configurations
- Testing Performed: Hi-pot and continuity tested on all standard assemblies
- Mechanical Features: Color-coded housings, keyed interface, latch-locking design
Applications
AUTOMATE Mini-FAKRA Type A cable assemblies are designed for:
- Advanced Driver-Assistance Systems (ADAS)
- V2X communications (Vehicle-to-Everything)
- In-vehicle infotainment and media systems
- Automotive camera and sensor modules
- Navigation and telematics systems
- Smart antenna and data routers
- High-speed data transfer and networking within the vehicle architecture
Browse our growing portfolio of AUTOMATE Mini-FAKRA Type A cable assemblies for use in today’s connected vehicles. If your design requires unique configurations, our engineering team can assist in developing a custom assembly to meet your exact requirements.
