Coaxial Insert Connectors

Coaxial insert connectors from Amphenol RF are precision-engineered components that allow reliable signal transfer from cable to PCB or subassembly modules. Available in both plug and jack variants, these inserts support a variety of 50 Ω cable types—including RG‑58, RG‑174, RG‑316, RG‑405, and conformable microcoax—enabling versatile integration in space-constrained designs without sacrificing RF integrity. Their robust mechanical and electrical properties ensure strong contact, low loss, and consistent performance across applications.

Ideal for high-frequency and high-reliability environments, coaxial inserts simplify custom cable assembly and modular sub-system design. These inserts offer a cost-effective alternative to overmolded terminations, allowing engineers to optimize signal paths while maintaining clean, standardized connection interfaces.

Features and Benefits

• Wide cable compatibility: Supports standard RG and specialty microcoax cables
• Insertable format: Plug into modules or PCBs with consistent mechanical fit
• Precise impedance matching: Maintains 50 Ω signal integrity across interface
• Durable construction: Machined inserts with gold-plated contacts resistant to wear
• Flexible mating configurations: Various plug/jack options for blanket system design

Key Technical Details

• Cable types: RG‑58, RG‑174, RG‑316, RG‑405, conformable microcoax (e.g. 0.047″, 0.086″)
• Termination options: Straight crimp, solder versions available for different cable styles
• Insert geometry: Designed for tight die cavities in PCB/subsystem assemblies
• Contact design: Optimized for low loss and reliable return loss performance
• Deployment readiness: Ideal for custom cable harnesses or factory-installed modular units

Applications

• Wireless test and measurement – feed-through connection panels in test racks
• Embedded RF modules – modular board-to-board or cable-to-board RF interfaces
• Automotive and avionics subassemblies – compact RF inserts in sensor and antenna harnesses
• Network and broadcast submodules – field-serviceable RF blocks with coax ports
• Custom cable bundles – assemble factory-ready cable harnesses with standardized RF ends

Browse our selection of coaxial insert plugs and jacks tailored to your cable type and assembly environment. For custom cable assembly, unique module integration, or specialized connector designs, contact our application engineering team to find the best solution for your project.
