Amphenol RF is pleased to announce the expansion of our ultraminiature product portfolio with a new AMC to BNC adapter. This new option for ultraminiature connectivity allows the secure bayonet coupling mechanism featured on the popular BNC interface to be mounted to the outside of a panel. This allows for easy attachment of an antenna or compatible BNC cable assembly. Inside the panel, an AMC jack, fully compatible with industry-standard U.FL and MHF1 products, can be connected to any length jumper assembly to mate with an ultraminiature module inside the box.
The durable AMC to BNC adapter is machined from brass and nickel-plated with PTFE insulator and a gold-plated, beryllium copper contact. The 50-ohm performance up to 6 GHz is well-suited for most commercial or industrial applications, as well as IoT and smart products. This adapter joins a robust portfolio of coaxial adapters engineered for a wide variety of traditional and emerging technologies.
The durable AMC to BNC adapter is machined from brass and nickel-plated with PTFE insulator and a gold-plated, beryllium copper contact. The 50-ohm performance up to 6 GHz is well-suited for most commercial or industrial applications, as well as IoT and smart products. This adapter joins a robust portfolio of coaxial adapters engineered for a wide variety of traditional and emerging technologies.
Learn more: AMC Product Series
