Amphenol RF showcases innovative solutions for customer-specific applications

Amphenol RF’s Locking FAKRA to MHF I LK cable assemblies deliver robust, high-frequency performance with a secure locking mechanism, engineered specifically for environments exposed to continuous vibration and motion. Supporting frequencies up to 6 GHz, these assemblies ensure stable and reliable electrical connections, making them ideal for cutting-edge applications in drones, smart cabins, ADAS, driver monitoring, and RFID systems.

Amphenol RF provides comprehensive custom RF solutions tailored to meet specific design requirements, from concept through mass production.

The FAKRA to SMA Adapter datasheet describes Amphenol RF’s FAKRA to SMA adapters, which connect FAKRA-based automotive systems to SMA RF devices using a push-on FAKRA and threaded SMA interface for secure, application-specific connections up to 4 GHz. The adapters feature rugged nickel-plated brass bodies, gold-plated contacts, PTFE insulation, and glass-filled nylon housing, providing excellent return loss, high mating durability (500+ cycles), and reliable performance from −65°C to +165°C in automotive, industrial automation, telecom, connected vehicle, and RF test applications.

Amphenol RF offers advanced RF interconnect solutions tailored for camera and vision systems used in automotive and industrial applications. These solutions include ruggedized, waterproof, and vibration-resistant connectors, ideal for high-frequency and high-speed data transmission.

Amphenol RF presents a comprehensive, high-performance portfolio of RF interconnect solutions, engineered to meet the rigorous demands of modern communications and electronic systems across industries. With decades of leadership in coaxial technology, this catalog showcases cutting-edge product lines, each designed for precision, reliability, and adaptability.

The AFI DART Cut Sheet showcases a cutting-edge RF interconnect solution designed for high-speed, high-reliability applications. The document highlights the DART series' compact, durable design, making it ideal for space-constrained environments while maintaining exceptional signal integrity. Engineered for high data rates and low latency, the DART connectors are built to withstand harsh environmental conditions, ensuring long-term performance and durability.

The Amphenol RF AUTOMATE® Mini-FAKRA Type A connectors offer an advanced automotive connector system. These features make the AUTOMATE Mini-FAKRA Type A connectors ideal for high-bandwidth automotive applications such as ADAS, GPS navigation, and 360-degree surround view cameras.

The Amphenol 2003 Full Line Catalog features a comprehensive range of connectors, including subminiature (MMCX, MCX, 1.0/2.3, SMB, SMC, SMA), miniature (BNC, TNC, Reverse Polarity), and standard types (Twinaxial, Twin BNC, Triax, UHF, Mini-UHF). Each section provides detailed specifications, available configurations, and applications for various industries, such as telecommunications, instrumentation, military, and industrial use. The catalog also includes cable assembly instructions and a glossary for additional support.

The Amphenol 2006 Full Line Catalog includes a comprehensive range of connectors and cable assemblies for various applications. The catalog also covers environmental compliance and quality assurance measures, showcasing Amphenol's commitment to reliable and high-performance interconnect solutions.

The Amphenol Connex Catalog features a comprehensive range of high-quality RF and microwave coaxial connectors, suitable for various applications including instrumentation, military-aerospace, broadband, RFID, and telecommunications. It offers a wide selection of connectors such as MMCX, MCX, SMA, SMB, BNC, TNC, UHF, and 7/16, along with custom cable assemblies and robust technical support​​.

The Amphenol RF 2.2-5 Product Data Sheet highlights the 2.2-5 connector series, designed for high-performance RF applications requiring compact size, low PIM, and superior electrical performance. This connector series is engineered to support high-frequency, low-loss signal transmission, making it ideal for 5G networks, small cells, and distributed antenna systems (DAS). With a rugged, weatherproof design, these connectors ensure reliable performance in harsh environments while maintaining ease of installation through various coupling mechanisms, including threaded, push-pull, and hand-screw options.

The 4.3-10 Connector Cut Sheet provides a detailed overview of the 4.3-10 RF connector series, designed for superior performance in high-frequency applications. This document outlines the key features of the 4.3-10 connectors, including their low PIM (Passive Intermodulation) performance, compact design, and high durability, making them ideal for telecommunications, wireless infrastructure, and RF signal transmission. The connectors are engineered for easy installation, offering a user-friendly interface with threaded, push-pull, and hand-screw coupling mechanisms to ensure secure connections.

Amphenol RF's 18 GHz N-Type connectors extend the frequency range of the traditional N-Type product line to 18 GHz, providing excellent low PIM performance in a durable, medium-sized package. These connectors are ideal for rugged, outdoor applications requiring high power handling and vibration resistance, with applications in microwave, wireless infrastructure, and radar systems.

The Amphenol RF FAKRA to AMC Cable Assemblies datasheet highlights fixed-length assemblies designed for automotive and IoT applications. These IP67-rated assemblies combine FAKRA connectors with micro-miniature AMC connectors on 1.37 mm ultra-flexible coax cable, providing compact and sealed solutions ideal for DSRC, V2X, V2V technologies, 360-degree cameras, ADAS, smart boxes, and remote control access​​.

Amphenol Micro Coaxial (AMC) connectors are low-profile solutions with a 2.5mm mating height and a 3mm x 3mm footprint, designed for portable and mobile devices. These connectors support high-frequency transmission from DC to 6 GHz, feature easy snap-on/off mating, and are compatible with Hirose U.FL and IPEX MHF1 series, making them ideal for applications like antennas, Bluetooth, GPS, WLAN, and cellular devices.

The Field Installable N-Type Connector Cut Sheet presents a high-performance N-Type connector designed for quick and efficient field installation without requiring special tools. Engineered for low-loss, high-frequency applications, this connector ensures secure and reliable RF connections in demanding environments. It features a rugged, weatherproof design, making it ideal for outdoor and industrial use, while its low PIM (Passive Intermodulation) performance supports high-quality signal integrity.

The Amphenol RF PSMP Cut Sheet highlights the PSMP connector series, a versatile RF solution engineered for high-power applications requiring robust performance and flexibility. This series is designed to handle high-frequency signals with excellent electrical performance, making it ideal for base stations, power amplifiers, and industrial applications. The PSMP connectors feature a compact, high-reliability design with options for smooth bore and full detent mating styles, ensuring secure connections while accommodating misalignment.

Amphenol Micro Miniature Coaxial (AMMC) connectors are designed for portable and mobile devices, featuring a low profile with a 1.4 mm mated height and a 2 mm x 2 mm footprint. These connectors support high-frequency transmission from DC to 6 GHz, offer easy snap-on/off mating, and are compatible with Hirose W.FL and IPEX MHF III series, making them ideal for applications such as antennas, Bluetooth, GPS, WLAN, and cellular devices.

The HD-EFI product series by Amphenol RF offers micro-miniature interfaces designed for high-performance applications with a frequency range from DC to 6 GHz. These 50 ohm products are ideal for board-to-board applications, featuring versatile PCB mounts and bullet lengths, and providing up to 1.4 mm axial and radial float. HD-EFI connectors are available in various configurations, including through-hole, surface mount, edge launch, and thread-in, and support blind mating with crash-proof designs​​.

The "Sealed FAKRA Cut Sheet" highlights FAKRA/USCAR mechanical coding for connectors. These connectors are designed for secure and reliable automotive applications, featuring mechanical and color coding to prevent mismating. The sealed FAKRA connectors are IP67 rated, providing protection against dust and temporary submersion in water, making them ideal for use in harsh environments​​.

The "Connectors Optimized for Low Loss Cables" guide by Amphenol RF features redesigned SMA, TNC, and N-Type connectors specifically tailored for Low Loss cables. These connectors, which include straight and right-angle plugs and jacks, provide enhanced shielding, improved grounding, and low signal loss for applications requiring high reliability, such as smart city infrastructure and IoT antenna systems. They support frequencies up to 12.4 GHz for SMA and 6 GHz for TNC and N-Type connectors, ensuring consistent electrical performance and quick, secure assembly with standard hex crimp tooling​​.

The Amphenol RF SMA Panel Mount Receptacles cut sheet details high-performance connectors supporting frequencies from DC to 18 GHz. These stainless steel receptacles are available in multiple panel mounting configurations, including 2 and 4-hole flanges, with various termination options such as post contacts, solder cups, and tab contacts. The connectors are suitable for applications like RF amplifiers, microwave filters, and power dividers, offering excellent VSWR performance and robust mechanical construction​​.

The Amphenol Connex Cable Connector Guide provides an extensive selection of RF connectors and adapters, detailing common parts for popular cable types. The guide emphasizes uncompromised quality, vast selection, and superb technical support, while also offering customization options for specific customer needs. It includes information on crimp tooling compatible with industry-standard crimp die set dimensions, ensuring reliable and efficient assembly​​.

The Amphenol RF FAKRA Cable Assemblies cutsheet details fixed length assemblies using RG-58 and RG-174 cables, featuring FAKRA connectors suitable for high-frequency transmission up to 3 GHz. These universally keyed connectors are available in various configurations and lengths from 12 inches to 5 meters, ideal for automotive applications like ADAS, GPS, and infotainment systems​​.

The Amphenol RF AUTOMATE Type A Mini-FAKRA connector series offers a high-performance, space-efficient solution for automotive applications, supporting data transmission up to 20 Gbps. These connectors feature a compact, modular housing that saves up to 80% installation space compared to traditional FAKRA connectors and are available in single, dual, and quad-port configurations. They are ideal for applications such as 360-degree surround view cameras, ADAS, GPS navigation, high-bandwidth infotainment, and V2X communication. The connectors provide low engagement and disengagement forces, impact resistance, and visual guidance through color-coded housings to prevent mis-mating.

The Amphenol RF FAKRA to AMC4 Cable Assemblies Data Sheet highlights a versatile, high-performance interconnect solution designed for automotive, IoT, and compact RF applications. These cable assemblies combine the secure, high-reliability FAKRA interface with the ultra-miniature AMC4 connector, ensuring seamless integration in space-constrained designs without compromising signal integrity. Engineered for low-loss transmission and robust mechanical performance, they are ideal for antenna connections, telematics, and wireless communication systems.

The Amphenol RF FAKRA Technical Guide outlines the features and applications of FAKRA connectors, which are designed for the automotive industry to support systems like GPS, cellular, Bluetooth, and satellite radio. The guide highlights their compliance with FAKRA and USCAR standards, their ability to handle frequencies up to 6 GHz, and the introduction of the AUTOMATE® (mini-FAKRA) series for higher data transmission rates up to 20 Gbps, suitable for autonomous and connected vehicles.

The Amphenol RF FAKRA to SMA Cable Assemblies Datasheet details pre-configured 50 ohm cable assemblies available in various lengths, designed for automotive and industrial applications such as ADAS, GPS, RFID, and wireless infrastructure. These assemblies feature flexible cables and high-quality connectors, providing reliable performance up to 3 GHz without the need for additional tooling.

Amphenol RF's AUTOMATE Mini-FAKRA to IP67 FAKRA breakout cables feature a quad-port Mini-FAKRA jack to four IP67 FAKRA jacks on low-loss RG-174 cable. These assemblies, designed for high-bandwidth automotive and industrial applications such as 360-degree cameras and ADAS, offer secure snap-on interfaces with low engagement forces, providing high performance up to 3 GHz. They feature rugged, impact-resistant housing with universal Z color coding and mechanical keying for intermateability, ensuring easy and reliable installation.

The Amphenol RF Generation 4 FAKRA Solutions Guide details the latest generation of FAKRA connectors, featuring an upgraded SMB connector design with fully automated cable termination and compliance with USCAR and FAKRA 2 standards. These connectors support high-volume automotive applications such as surround cameras, infotainment, GPS, and emerging technologies like autonomous vehicle systems, offering benefits like ruggedized housings, multiple key codes, and reliable performance up to 6 GHz.

FAKRA Generation 4.0 Solutions Guide featuring FAKRA cable and pcb connectors. Stamped and formed designs are ideal for high speed automated assembly.

The Amphenol RF Generation 4 FAKRA Solutions Guide details the latest generation of FAKRA connectors, featuring an upgraded SMB connector design with fully automated cable termination and compliance with USCAR and FAKRA 2 standards. These connectors support high-volume automotive applications such as surround cameras, infotainment, GPS, and emerging technologies like autonomous vehicle systems, offering benefits like ruggedized housings, multiple key codes, and reliable performance up to 6 GHz.

The Amphenol RF Generation 4 FAKRA Solutions Guide details the latest generation of FAKRA connectors, featuring an upgraded SMB connector design with fully automated cable termination and compliance with USCAR and FAKRA 2 standards. These connectors support high-volume automotive applications such as surround cameras, infotainment, GPS, and emerging technologies like autonomous vehicle systems, offering benefits like ruggedized housings, multiple key codes, and reliable performance up to 6 GHz.

The Amphenol RF FAKRA Cable Assemblies Overview highlights high-performance TFC-302LL cable assemblies designed for automotive and industrial applications. It details their low-loss characteristics, secure FAKRA connectors, and suitability for high-frequency signal transmission in demanding environments.

Amphenol RF's AUTOMATE Type A Mini-FAKRA to FAKRA breakout cables feature compact, modular housings with multi-port configurations, utilizing low-loss, flexible cables. These assemblies are ideal for high-bandwidth automotive and industrial applications, including 360-degree cameras, advanced driver assistance systems (ADAS), and GPS, providing reliable performance up to 6 GHz.

Amphenol RF's FAKRA rear mount bulkhead crimp plugs are engineered for automotive and industrial applications, supporting TFC 302LL and RG-174 cables. These connectors provide reliable electrical performance up to 6 GHz, feature IP67-rated waterproofing, and are available in various color-coded key codes for easy installation.

Discover how Amphenol RF’s AUTOMATE® Mini-FAKRA connecters and cable assemblies offer reliable, high-performance connectivity for automotive and industrial applications. In this video, we explore the features of our standard mini-FAKRA solutions and dive into the custom engineering capabilities that set us apart. Whether you need unique configurations, specialized materials or enhanced performance for harsh environments, our global team of engineers can design a solution tailored to your exact design specifications. From compact, modular housing to flexible cable options, Amphenol RF delivers high-quality FAKRA solutions for your most demanding applications. Learn how our expertise can power your next project! Don’t forget to subscribe for more insights into our advanced RF interconnects and custom-engineered solutions. AUTOMATE® Product Catalog: https://www.amphenolrf.com/library/download/link/link_id/600297/ Check us out on social media: https://www.facebook.com/officialAmphenolRF https://www.linkedin.com/company/amphenol-rf/mycompany/ https://www.twitter.com/AmphenolRF Our Website: https://www.amphenolrf.com

Amphenol RF's AUTOMATE® Mini-FAKRA Type A connector series is the latest in automotive interconnect technology. This space-conscious, high-performance interface is central to the next generation of vehicle applications. Learn more: https://www.amphenolrf.com/AUTOMATE Data sheet: https://bit.ly/36llY9K Automotive Overview: https://bit.ly/2MCSm0I Automotive Solutions Guide: https://bit.ly/2Yr7gcI

Welcome to the next era of connectivity! In this video, we unveil the latest generation of FAKRA connectors, revolutionizing the industry with their cutting-edge features and performance. These connectors are engineered to meet the growing demands of modern applications, offering enhanced reliability, durability, and versatility. Check us out on social media: www.facebook.com/officialAmphenolRF www.linkedin.com/company/amphenol-rf/mycompany/ www.twitter.com/AmphenolRF Our Website: www.amphenolrf.com
