New Products

The end-launch rear-mount SMA Bulkhead connector offers low VSWR performance which ensures reliable impedance matching and signal integrity. The end-launch PCB interface has a 10 millimeter center pin which supports controlled impedance transitions at the board edge. This SMA bulkhead jack is highly optimized for RF and microwave instrumentation, enclosure-mounted communication systems and industrial RF equipment applications.

This connector is constructed from gold-plated brass body and beryllium copper contact, which improves conductivity for a 26.5 GHz frequency range capacity. It also features a gold-plated brass hex nut and washer, along with a natural PTFE insulator. The 500 mating cycle rated interface of the connector meets the MIL-STD-348 specification ensuring compatibility with standard SMA mating connectors.

Non-magnetic SMPM connectors are engineered with non-ferrous materials and are available in smooth bore and full detent configurations compatible with existing non-magnetic bullet adapters for a full board-to-board solution. The small footprint of the SMPM interface allows these connectors to be used in a variety of applications where space constraints are a concern making it ideal for applications such as MRI, quantum computing and instrumentation equipment

Non-magnetic SMPM connectors utilize a gold-plated beryllium copper body and contact along with a PTFE insulator, ensuring excellent electrical conductivity. Non-magnetic SMPM connectors prevent potential hazards that come from magnetic interference and ensure that RF signals are not compromised which is essential for critical medical technology such as magnetic resonance angiography (MRA), MRI scanners, medical imaging components and specialized surgical instrumentation.

Single crimp N-Type connectors offer the ability to attach the connectors to cable with only one crimp of the ferrule, eliminating the need to crimp the contact separately. These connectors are IP67-rated when mated and feature a hex-shaped body for easy handling. Single-crimp N-Type connectors are well-suited for applications that require installation in the field with minimal tools such as antennas, base stations and radar systems.

These N-Type connectors are engineered with a nickel-plated brass body and gold-plated beryllium copper contact, and feature a PTFE insulator. They provide reliable RF performance up to 6 GHz and allow for a minimum of 500 mating cycles. The durable medium-sized interface features a threaded coupling mechanism for secure mating and vibration-resistance which makes them ideal for equipment located in harsh environments.

USCAR compliant Mini-FAKRA connectors are designed to support new vehicle designs. This multi-port solution is available in a variety of PCB and cable-mount configurations including straight and right-angle single, dual and quad-port variations. Mini-FAKRA can be used in a wide variety of automotive designs where high data transmission rates are required such as compute modules, wire harnesses, sensors and camera technology.

AUTOMATE® Mini-FAKRA USCAR compliant connectors have undergone extensive validation which includes rigorous testing to simulate field performance for approximately 150,000 miles or 15 years, and environmental testing such as thermal shock, vibration and mechanical shock, temperature and humidity cycling, and high temperature exposure. This certification showcases Amphenol’s commitment to providing customers with the highest level of quality, reliability and performance.

This 2.4 mm straight jack to jack adapter is engineered for excellent impedance control and mechanical durability. This compact, 50-ohm solution supports accurate, repeatable measurements across advanced RF applications and is ideal for use in dense instrumentation layouts within 5G, aerospace and test instrumentation equipment. This new 2.4 mm adapter is machined with passivated stainless-steel bodies and a gold-plated beryllium copper contacts for enhanced conductivity and durability in harsh environments. The materials used in the production of these adapters were selected to provide corrosion resistance, dependable mechanical stability and repeated connect and disconnect in production environments.

The 2.4 mm adapter interface offer high frequency broadband performance up to 40 GHz making it well suited for designs that require accurate transmission of micro-wave and millimeter-wave signals across test and measurement systems. This adapter joins a growing offering of mmWave products available as off-the-shelf solutions.

2.92 mm connectors on 0.141” conformable cable enable stable, low loss high-frequency test and instrumentation usage. Broadband electrical performance up to 40 GHz provides support for millimeter-wave signal integrity in laboratory and production environments. A low VSWR ensures repeatable measurements, minimized signal reflections and guarantees dependability. 2.92 mm connectors support flexible cable routing and panel-mount system designs and are highly suited for 5G, aerospace and broadband communication applications.

The connectors are available in straight plug and bulkhead jack configurations with gold-plated stainless steel bodies coupled with beryllium copper contacts ensuring excellent corrosion resistance and longterm mechanical durability. The insulator is naturally finished Ultem 1000 with an insulator disc made from naturally finished PTFE. The quality materials used in these connectors allows them to withstand a wide temperature range, which ensures performance in a variety of environments.
