使用非铁材料设计的 MCX 连接器消除磁场干扰

Amphenol RF 很高兴地宣布，我们的 MCX 产品系列已扩展到包括 RG-174 电缆的其他电缆组件选项。

Amphenol RF 很高兴地宣布扩大我们的电缆组件产品组合，增加了 BNC 至 MCX 和 MMCX 配置。

Amphenol RF 很高兴能扩展其电缆组件产品，增加采用柔性 1.13 mm 微同轴电缆设计的 MCX 和 MMCX 电缆组件。

安费诺射频公司通过推出MCX组件扩展其线缆组件产品线，该组件专为无线通信系统提供安全、耐候的连接解决方案。

安费诺射频公司通过推出新型MCX组件，扩展了其预配置线缆组件产品组合，这些组件专为工业和户外无线系统提供可靠连接器而设计。

安费诺RF（Amphenol RF）扩展了其预配置线缆组件产品组合，推出了新款MCX组件，旨在为工业及户外无线系统提供可靠的连接器。

Amphenol RF 推出更多非磁性 MCX 连接器配置，以确保射频信号在敏感应用中不会受到磁干扰的影响。

Amphenol RF's 12G MCX connectors support 12Gbps data transfer, facilitating the transmission of high-resolution 4K and Ultra-HD video in a compact size. These connectors are ideal for broadcast modules and video routers, offering both PCB and cable configurations with a push-on coupling mechanism, optimized for 75-ohm 12G SDI applications.

Amphenol RF offers 12G SDI broadcast solutions designed for Ultra High Definition (4K) video, utilizing BNC, HD-BNC, and MCX connectors optimized for 12 Gbps data transfer. These connectors provide reliable, high-quality signal transmission on a single channel, supporting various applications including mobile broadcast, HD cameras, and video routers.

Amphenol RF's MMCX Cable Assemblies provide broadband performance with low reflections, featuring quick connect/disconnect snap-on mating in a micro-miniature package size. These 50 ohm assemblies, available in various standard lengths, are ideal for applications such as broadband modules, Wi-Fi access points, GPS units, and antennas, offering reliable performance up to 6 GHz.

Amphenol RF's MCX Cable Assemblies provide broadband performance with low reflections, featuring a quick connect/disconnect snap-on mating mechanism. These 50 and 75 ohm assemblies, available in various lengths and configurations, are ideal for broadcast equipment, Wi-Fi access points, GPS units, and wireless network antennas, offering reliable electrical performance up to 6 GHz (12 GHz for 75 ohm products).

Amphenol RF's MMCX Ultraminiature Product Series offers 50 ohm connectors and cable assemblies designed for micro-coax cable types, providing broadband performance with low reflection and quick connect/disconnect snap-on mating. These assemblies are ideal for space-constrained applications such as IoT devices, Wi-Fi access points, GPS units, and external antenna connections, with configurations that allow for flexible routing within enclosures.

Amphenol RF's MCX Ultraminiature Product Series includes robust, 50 ohm connectors and cable assemblies designed for space-constrained applications such as IoT devices and handheld electronics. These assemblies feature quick connect/disconnect snap-on mating, micro-miniature size, and are available in various configurations, making them suitable for external antennas and internal connections within devices.

The Amphenol RF MCX series catalog showcases a family of micro-coaxial (MCX) connectors offering broadband performance from DC to 6 GHz (and up to 12 GHz in 75 Ω broadcast variants) with 50 Ω or 75 Ω impedance options, featuring a compact snap-on coupling mechanism for weight- and space-constrained applications.

The Amphenol RF MCX Cable Assemblies Data Sheet highlights between-series board-to-panel cable solutions designed for wireless communication modules. These assemblies combine compact MCX interfaces with rugged, sealed bulkhead connectors to enable reliable RF connectivity in space-constrained and environmentally exposed applications.

The Amphenol RF MMCX cable assemblies datasheet outlines pre-configured 50-ohm RF cable solutions using flexible RG-174 coax for reliable connections in wireless communication modules. It highlights available connector configurations, electrical performance characteristics, and suitability for applications such as IoT, GPS, Wi-Fi, and other compact RF systems.

This datasheet highlights Amphenol RF’s MCX cable assemblies for wireless communication modules, featuring between-series board-to-panel configurations built on flexible RG-316 cable for reliable performance up to 6 GHz. The assemblies combine MCX straight or right-angle plugs with rugged, IP67-rated bulkhead connectors—including SMA, RP-SMA, TNC, RP-TNC, and N-Type—designed to provide secure, sealed connections that protect systems from temporary water and fluid ingress. Optimized for short-distance RF applications, these cable assemblies offer high heat resistance, durability, and low signal loss, making them well-suited for portable IoT devices, drones, GPS/GNSS, Wi-Fi, and demanding industrial, agricultural, and construction environments, with a wide range of standard and custom cable lengths available.

The Amphenol RF MMCX series catalog features a compact line of 50-ohm RF connectors delivering reliable performance from DC to 6 GHz. With a 3.5 mm snap-on interface rated for 500 mating cycles, the series supports secure, tool-free connections in space-constrained designs.

September 23, 2020 - Today’s 4K and emerging 8K video standards require an enormous amount of bandwidth. And, with all that bandwidth, there are new demands on our interconnects. In this episode of Chalk Talk, Amelia Dalton chats with Mike Comer and Ron Orban of Amphenol RF about the evolution of broadcast technology and the latest interconnect solutions that are required to meet these new demands. More information about Amphenol RF Adapters & Cable Assemblies for Broadcast: https://bit.ly/3iYYECS

View full article: https://www.allaboutcircuits.com/new-industry-products/amphenol-rf-bnc-to-mcx-cable-assemblies-new-product-brief View product at Mouser.com: https://bit.ly/2Vp4mmU Amphenol RF BNC to MCX Cable Assemblies are designed to deliver 4K video and other high bandwidth data on a compact interconnect without compromising signal quality. The cable assemblies offer a 75 ohm impedance and use Belden 4855R cable, ensuring quality transmission from the source to the receiver. For more information, as well as all the latest All About Circuits projects and articles, visit the official website at http://www.allaboutcircuits.com/ Check out Mouser's profile on All About Circuits and see more product briefs and articles at https://www.allaboutcircuits.com/author/mouser-electronics For more new products at Mouser, visit https://www.mouser.com/new/ Don't have AAC account yet? Register here! It's free and always will be. https://forum.allaboutcircuits.com/register Subscribe on YouTube: https://www.youtube.com/c/AllAboutCircuitsVideo Like us on Facebook: https://www.facebook.com/allaboutcircuits Follow us on Twitter: https://twitter.com/AllAboutCircuit Follow us on LinkedIn: https://www.linkedin.com/company/allaboutcircuits
