AMC4 Right Angle Plug to SMA Straight Bulkhead Jack IP67 1.13 mm 50 Ohm 100 mm
095-902-502-100
Part Status:
Active
Product Specifications
See Similar
Product Specifications
| Attributes | Details |
See Similar
Select the attributes below to view similar products
|
|---|---|---|
| Applications |
Ultraminiature, Waterproof IP Rated
|
|
| Armor Option |
Without Armor
|
|
| Cable Assembly Length |
3.94 in (100 mm)
|
|
| Cable Assembly Type |
Between-Series
|
|
| Cable Config |
AMC4 Plug to SMA Jack
|
|
| Cable Config 2 |
AMC4 Pl R/A to SMA Jk Str Bkhd IP67
|
|
| Cable Type Cable Assemblies |
1.13 mm Micro-Cable
|
|
| Country of Origin |
CN
|
|
| ECCN |
EAR99
|
|
| Frequency (Max GHz) |
6
|
|
| HTS Code |
8544.20.0000
|
|
| Impedance (Ohms) |
50
|
|
| IP Rating |
IP67
|
|
| Low PIM |
No
|
|
| Mil Qualified |
Not Mil Qualified
|
|
| Non Magnetic |
Contains Magnetic Materials
|
|
| Panel Mounting Feature |
Not Applicable
|
|
| PFAS |
PFAS Status Undetermined
|
|
| Unit Weight (Grams) |
7.000
|
|
All Related Documents
All Related Documents
Locked items require an Amphenol RF account
Log in /Register
| Document Title | Type | Publish Date |
|---|---|---|
|
095-902-502-XXX STP 3D Model
(Size: 2.1 MB)
|
stp |
11/11/2025 |
| 095-902-502-XXX PDF Customer Drawing (Size: 341.6 KB) | pdf |
5/28/2021 |
