MHV (Miniature High Voltage) connectors are bayonet locking interconnects used for high voltage applications up to 5000 volts.

They are similar in size to, but not designed to mate with the BNC interface. MHV connectors conform to MIL-STD-348 and offer a quick-connect functionality that is used where transmission of high voltage is required.

Features and Benefits
  • Used for high voltage applications up to 5000 volts DC
  • Quick connect functionality
  • Conforms to MIL 348 standards
  • Nickel plating
  • Transmission Lines
  • High Voltage Power Supplies
  • Nuclear Control Instrumentation
  • X-Ray

MHV Connectors Specifications


Impedance Non-Constant
Frequency Range DC - 500 MHz
Voltage Rating 1500 Volts RMS Continuous
Dielectric Withstanding Voltage 5000 VRMS Max


Mating Cycles 500 Min
Coupling Mechanism Bayonet
Interface Specification MIL-STD-348
Note: These characteristics are typical and may not apply to all connectors.
Connector configurations may affect performance.
